7623Manual Control: YesCoil Voltage: 24vFeatures: Manual control switch provides an added level of safety allowing control with or without power, and offering "Locked Off" capability for servicing Includes ML-Series Remote Control Contura Switch PN 2146 500 Ampere continuous rating Magnetic Latch (ML)-ACR draws very low current (<10 mA to monitor terminal voltage) in the "ON" or "OFF" states, and draws moderate current for very short time when changing state Start Isolation (SI)-Can be configured for temporary isolation of House loads from Engine circuit during engine cranking to protect sensitive electronics Engine Isolation (EI)-Can be configured for isolation of two engines while both are running to protect engine electronics and maximize alternator output Senses charging on two battery banks Supports high-output alternators up to 500 Amps LED output to remotely indicate when batteries are combined, isolated, in voltage lockout, in Start or Engine isolation 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22mm) stud length accepts multiple cable terminals Label recesses for circuit protection Silver alloy contacts provide high reliability for switching live loads WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

m-Series Battery Switch Paralleling Link Bus Material: Tin-Plated Copper Continuous Rating: 250 Amperes DC WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

7649 Mini Add-A-BatteryWhat does the Mini Add-A-Battery do?Adding a second battery prevents getting stranded with a dead battery by isolating the start battery from the house loads that can quickly discharge a battery. The Mini Add-A-Battery offers a compact, simple way to control the switching with the m-Series Dual Circuit PlusT Battery Switch and automatically share a single source of charging between two batteries with the Mini ACR Automatic Charging Relay. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Continuous Amperage: 65a Box Dimensions: 4"H x 8"W x 12"L WT: 1.65 lbs UPC: 632085076498 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

SmartShunt 500A/50MV IP65 Bluetooth Battery MonitorThe Smart Battery ShuntThe SmartShunt is an all-in-one battery monitor, only without a display. Your phone acts as a display. The SmartShunt connects via Bluetooth to the VictronConnect app on your phone (or tablet) and you can conveniently read out all monitored battery parameters, like state of charge, time to go, historical information, and much more.Alternatively, the SmartShunt can be connected and read by a GX device. Connection to the SmartShunt is made via a VE.Direct cable.The SmartShunt is a good alternative for a BMV battery monitor, especially for systems where battery monitoring is needed but less wiring and clutter are wanted.The SmartShunt is equipped with Bluetooth, and a VE.Direct port and a connection that can be used for: monitoring a second battery, midpoint monitoring, or a temperature sensor.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Continuous Amperage: 500A Lockable: No Box Dimensions: 4"H x 4"W x 6"L WT: 1.15 lbs UPC: 8719076057895 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

SolidSwitch 104 for DC Loads Up To 70V/4AFeatures: The SolidSwitch 104 will switch DC loads of up to 70V/4A and can be controlled by a low-power digital signal. The DC load can be resistive, capacitive or inductive (such as the coil of a high-power contactor). The SolidSwitch is not reverse polarity protected and not short circuit proof. Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

VE.Bus BMS NGThe VE.Bus BMS NG is an all-in-one Battery Management System (BMS) for Victron Lithium NG batteries (not compatible with Lithium Battery Smart batteries), designed for systems with Victron inverters or inverter/chargers using VE.Bus communication. It monitors and protects the batteries against overvoltage and under-voltage of any individual cell, and also against over-temperature or under-temperature conditions.With built-in Bluetooth, it connects directly to all lithium NG batteries in the system for central monitoring via VictronConnect. It also receives current and state of charge data directly from the batteries, so there’s no need for a separate SmartShunt.The lithium NG batteries can be configured in series, parallel, or a combination of both, supporting 12V, 24V, and 48V systems. A maximum of 50 batteries can be used in 12V or 24V banks, and 25 batteries in 48V banks, enabling up to 192 kWh (12V), 384 kWh (24V), and 128 kWh (48V) of storage. Multiple Lynx Smart BMS units can be paralleled to expand capacity and ensure redundancy.Features: Bluetooth Smart: The VE.Bus BMS NG includes Bluetooth Smart for wireless configuration, monitoring, and firmware updates via the VictronConnect App. Instant Readout shows key data such as SoC, battery temperature, warnings, and alarms directly in the device list, without needing to connect. Load disconnect output: Controls the remote on/off input of a BatteryProtect, inverter, DC-DC converter, or other loads with remote on/off functionality to prevent deep discharge. Charge disconnect output: Controls the remote on/off port of chargers such as the Smart IP43 Charger, a Cyrix-Li-Charge relay, a Cyrix-Li-ct Battery Combiner, or a BatteryProtect, to prevent overvoltage. Pre-alarm output: Provides early warning for low battery voltage before disconnecting loads. Can drive a relay, LED, or buzzer. Remote on/off control: Allows external control of both load and charge disconnect outputs. LED indicators: Includes a blue LED for Bluetooth status and a red LED for warnings and errors. Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Continuous Amperage: 10 mA Box Dimensions: 2"H x 5"W x 7"L WT: 0.65 lbs UPC: 8719076063520 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

5511eDual Circuit Plus Battery Switch CE Marked Ignition protected - Safe for installation aboard gasoline powered boats Case design allows surface or rear panel mounting Meets American Boat and Yacht Council (ABYC) requirements for battery switches 3/8" - 16 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 3/8" and M10 ring terminals 7/8" stud length to accept multiple cable terminals Tactile textures indicate knob position by feel only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Positions: 1 AFD: No Continuous Amperage: 600a Box Dimensions: 3"H x 6"W x 9"L WT: 1.2 lbs UPC: 632085551155 Owner's Manual (pdf)Brochure (pdf)

Read more less

701 Contour Battery Master SwitchLabel Set (12 Labels) for non-standard labeling.

Read more less

Battery Selector SwitchPart No. 2111AFeatures New ergonomically styled turn knob provides easy On/Off switching Updated color scheme and graphics make it easier to determine switch status Longer stud lengths for improved assembly and easier cable routing Built with heavy-duty copper sweep contacts to ensure positive circuit control Rugged internal components protected by a tough, impact resistant polycarbonate housing that is impervious to the elements One year warranty WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Battery Tray with Straps for 24 Series Batteries Heavy duty Battery Tray with Strap for size #24 batteries. Includes hold down strap with a quick release buckle and four 1/4"x1" PH screws with washers. Injection molded polypropylene construction.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Battery Tray with Straps for 27 Series Batteries Heavy duty Battery Tray with Strap for size #27 batteries. Includes hold down strap with a quick release buckle and four 1/4"x1" PH screws with washers. Injection molded polypropylene construction.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

SmallBMS NGThe SmallBMS NG is an all-in-one Battery Management System (BMS) designed for Victron Lithium NG batteries (not compatible with lithium smart batteries). It monitors and protects the batteries by managing charge and load disconnects and providing pre-alarms for low battery voltage.The SmallBMS NG is a straightforward and cost-effective alternative to the VE.Bus BMS NG for applications that don’t require integration with Victron inverter/chargers. It provides essential lithium battery protection without the added complexity of VE.Bus communication is therefore not suitable for use with VE.Bus inverter/chargers such as MultiPlus and Quattro.With built-in Bluetooth, it connects directly to all lithium NG batteries in the system for central monitoring via VictronConnect. It also receives current and state of charge data directly from the batteries, so there’s no need for a separate SmartShunt.The lithium NG batteries can be configured in series, parallel, or a combination of both, supporting 12V, 24V, and 48V systems. A maximum of 50 batteries can be used in 12V or 24V banks, and 25 batteries in 48V banks, enabling up to 192 kWh (12V), 384 kWh (24V), and 128 kWh (48V) of storage. Multiple Lynx Smart BMS units can be paralleled to expand capacity and ensure redundancy.Features: Load disconnect output: Controls the remote on/off input of a BatteryProtect, inverter, DC-DC converter, or other loads with remote on/off functionality to prevent deep discharge. Charge disconnect output: Controls the remote on/off port of chargers such as the Smart IP43 Charger, a Cyrix-Li-Charge relay, a Cyrix-Li-ct Battery Combiner, or a BatteryProtect, to prevent overvoltage. Pre-alarm output: Provides early warning for low battery voltage before disconnecting loads. Can drive a relay, LED, or buzzer. Remote on/off control: Allows external control of both load and charge disconnect outputs. LED indicators: Includes a blue LED for Bluetooth status and a red LED for warnings and errors. Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

7701Manual Control: NoCoil Voltage: 12V DC 500 Ampere continuous rating for use as a remote battery switch for inboard gasoline or diesel engines, reducing long cable runs Magnetic latch only draws current when changing state of switch, drawing no current in "ON" or "OFF" state Silver alloy contacts provides high reliability for switching live loads Optional manual switch provides an added level of safety allowing control with or without power, and offering lockout capability for servicing 3/8" copper studs, using Blue Sea Systems superior one piece technology, suitable for 300 Amperes continuous rating and large cable connections WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

m-Series Dual Circuit Plus PN 6011(1) 100A C-Series Flat Rocker Circuit Breaker(2) 15A Push Button Thermal Circuit Breakers Designed for twin engine configurations Provides 24 hour circuit protection Provides main DC circuit protection in addition to high ampere load protection Protects electronics from sags and spikes caused by engine cranking Allows emergency cross connect between isolated battery banks Isolates the Engine circuit from the House circuit Simplifies battery switch operation Allows independent battery discharge Addition of an Automatic Charging Relay automates charging both batteries Includes 4218 - Square Format Labels and 4140 - 24 Hour Round Labels WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Compact Battery Selector & Main Disconnect Switches Polycarbonate Body with Brass Terminals Ignition Protected For use with 6 to 32 Volt Marine Electrical Systems Capacity - 315 AMPS Continuous, 450 AMPS 5 Mins. Intermittent Terminal Stud Size: 3/8" Width: 4" Height: 4" Depth: 3" Specifications: AFD: No Lockable: No Positions: 2 Box Dimensions: 3"H x 5"W x 8"L WT: 0.95 lbs UPC: 085226369230 Quick Guide (pdf)

Read more less

SmartSolar MPPT Charge Controller - 75V - 15AMPFeatures: Bluetooth Smart built-in The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.  VE.Direct For a wired data connection to a Color Control GX, other GX products, PC or other devices  Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Load output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage (48V model: interface with a relay). Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life. The load output is short circuit proof.  Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months. The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards, the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week.  Programmable battery charge algorithm See the software section on our website for details  Day/night timing and light dimming option See the software section on our website for details  Internal temperature sensor Compensates absorption and float charge voltage for temperature.  Optional external battery voltage and temperature sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 18-75v Charger Output - Amps: 15a Charger Output Voltage: 12v/24v Charging Banks: 1 Portable: No Box Dimensions: 2"H x 6"W x 6"L WT: 1.35 lbs UPC: 8719076040804 Quick Guide (pdf)Brochure (pdf)

Read more less

SmartSolar MPPT 150/45 Solar Charge ControllerA solar charger gathers energy from your solar panels, and stores it in your batteries.  Using the latest, fastest technology, SmartSolar maximizes this energy harvest, driving it intelligently to achieve full charge in the shortest possible time.  SmartSolar maintains battery health, extending its life.The SmartSolar charge controller will even recharge a severely depleted battery.  It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.Features: MPPT - Ultra Fast Maximum Power Point Tracking - By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage.  The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing. Remote Monitoring and Control - Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or another device via VictronConnect. Advanced Maximum Power Point Detection in case of partial shading conditions.  Outstanding conversion efficiency.  Natural convection cooling.  Automatic battery voltage recognition.  Flexible charge algorithm.  Over-temperature protection and power derating when the temperature is high.  Technical Specifications: Dimensions (L x W x H) - 7.3" x  5.2" x  2.8" (186 x 132 x 71mm)  Battery Voltage - 12/24/36/48V  Rated Charge Current - 45A Max. PV Short Circuit Current - 50A Maximum Efficiency - 98% Data Communication Port - VE. Direct In the Box: 150/45 Solar Charge Controller Instruction Manual  *Sold as an IndividualPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

e-Series Dual Circuit Plus PN 5511e(1) 100A C-Series Flat Rocker Circuit Breaker(2) 15A Push Button Thermal Circuit Breakers Designed for twin engine configurations Provides 24 hour circuit protection Provides main DC circuit protection in addition to high ampere load protection Protects electronics from sags and spikes caused by engine cranking Allows emergency cross connect between isolated battery banks Isolates the Engine circuit from the House circuit Simplifies battery switch operation Allows independent battery discharge Addition of an Automatic Charging Relay automates charging both batteries Includes 4218 - Square Format Labels and 4140 - 24 Hour Round Labels WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

BlueSolar MPPT Charge Controller - 75V - 15AMPFeatures: Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Load output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage. Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life. The load output is short circuit proof. Some loads (especially inverters) can best be connected directly to the battery, and the inverter remote control connected to the load output. A special interface cable may be needed, please see the manual.  Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months. The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week.  Programmable battery charge algorithm See the software section on our website for details  Day/night timing and light dimming option See the software section on our website for details  Programming, real-time data and history display options - Color Control GX or other GX devices: see the Venus documents on our website. - A smartphone or other Bluetooth-enabled device: VE.Direct Bluetooth Smart dongle needed Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 18-75v Charger Output - Amps: 15a Charger Output Voltage: 12v/24v Charging Banks: 1 Portable: No Box Dimensions: 2"H x 6"W x 6"L WT: 1.3 lbs UPC: 8719076025320 Quick Guide (pdf)Brochure (pdf)

Read more less

Medium Duty Main Battery Disconnect SwitchesIgnition ProtectedFor use with 12, 24 and 32 volt marine electrical systemscapacity - rated 250 amps continuous,360 amps intermittent Medium Duty Main Battery Disconnect Switch w/ Key Lock Specifications: AFD: No Lockable: Yes Positions: 1 Continuous Amperage: 250a Box Dimensions: 3"H x 6"W x 8"L WT: 0.9 lbs UPC: 085226560446 Quick Guide (pdf)

Read more less

GX LTE 4G-A Cellular Modem for GX Devices - North America OnlyThe GX LTE 4G is an accessory for GX devices. It is a cellular modem that supports 2G, 3G, and 4G technologies. It provides mobile internet for the system and a connection to the Victron Remote Management (VRM) portal.Built-in GPS ReceiverThe GX LTE 4G includes a built-in GPS receiver. When the optional active GPS antenna is installed, the system can be tracked as well as geo-fenced on the VRM Portal.The required accessory part number is GSM900200100 - Active GPS Antenna for GX GSM.GX CompatibilityThe GX LTE 4G can be used with any of the GX devices and requires Venus OS v2.60 or newer to be installed on the GX device.SIM CardIt requires a SIM card in the Mini-SIM format.When to Use a Mobile Router InsteadThe GX LTE 4G provides an internet connection for the GX device only. There is no option to share the internet with laptops, phones, or other devices. For installations where more devices need internet, such as a yacht or RV, consider installing a mobile router instead.Antennas and AccessoriesA small indoor LTE antenna is included. Optionally, Victron sells an outdoor LTE antenna, which increases the range.Part number GSM900100400 - Outdoor 4G GSM Antenna.Specifications: Region: For North America Used Module: SIMCom, SIM7600A Supported LTE Bands: 2, 4, 12 Supply Voltage Range: 8 - 70VDC Power Draw: 2.5W while 2G/3G/4G data transfer / <1.0W in idle mode / +0.4W if GPS is enabled Operating Temperature Range: -40 +50°C (-40 - 120°F) Power Cable (Included): 1.4m cable with inline fuse holder, terminal block, and 10mm ring terminals Inline Fuse (included): T3.15A250V Communication Specifications: USB Communication Port: Fixed 1.0m cable with USB-A connector (connects to the GX device) LTE Antenna Connector: Type SMA Female (optional 4G outdoor antenna GSM900100400) GPS Antenna Connector: Type SMA Female (optional GPS antenna GSM900200100) GNSS: GPS/Beidou/GLONASS/GALILEO/QZSS SIM Card: Regular Mini SIM (supports both 1.8V and 3V) Data Transmission (max. Download/Upload) LTE Cat-1: 10 Mbps / 5 Mbps Data Transmission (max. Download/Upload) 3G (HSPA+): 42 Mbps / 5.76 Mbps Data Transmission (max. Download/Upload) 2G (EDGE): 236.8 Kbps / 236.8 Kbps Data Transmission (max. Download/Upload) 2G (GPRS): 85.6 Kbps / 85.6 Kbps Status Indicator: Blue LED Installation & Dimensions: Dimensions (l x w x h): 106 × 42.5 × 22mm Weight: 0.08kg (0.177lbs) Wire Gauge (power cable): 0.5..1.5mm2 / AWG 28..16 or use supplied power cable Recommended Fuse Size: 500mA @ 12V / 250mA @ 24V / 100mA @ 48V or use supplied inline fuse In the Box: GX LTE 4G (with integrated USB cable) GSM 2G/3G/4G mini-rod antenna (for indoor use) DC power cable (with inline fuse and terminal block) Standrads: Safety: EN 60335-1 / EN 60335-2-29 / EN 62368-1 Emission / Immunity: ECE R10-5 QM: EN 9001:2015 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

M8 Circular Connector 3-Pole BMS BTV Extension Cables - Pair - 2MFeatures: 2-meter cable Extends the data cables that run from a 12.8 Volt Lithium-Ion battery to the BMS Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

M8 Circular Connector 3-Pole BMS BTV Extension Cables - Pair - 3MFeatures: 3-meter cable Extends the data cables that run from a 12.8 Volt Lithium-Ion battery to the BMS Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

Pro Installer 400A EZ-Mount Battery Selector Switch (1-2-Both-Off)As easy as 1, 2, 3, these revolutionary battery switches allow you to wire from the front. Never has installation been so easy and cabling so accessible. With their shared interconnection height, EZ-Mount battery switches "cluster" directly with the Pro Installer Busbar Range, resulting in the fastest, most compact installations. Optimized cable access makes installation a breeze. Pro Installer switches set the new benchmark with outstanding ergonomics, intuitive look/feel, and are engineered from the finest materials to withstand the harsh marine environment. The outstanding performance and features of this powerful new generation battery switch appeal to both the installer and end user. All ratings, footprints and features of the EZ-Mount switch match the high quality of our standard switches. Tested to UL1107 ignition protection, CE Tinned copper 10mm (3/8") studs Stainless steel washers/nuts Fiber reinforced plastics 400A Continuous / 600A 5 mins Intermittent / 1500A 10 secs Cranking Waterproof to IP66 Same interconnection height as Pro Installer Removable knob allows isolation during servicing 3 removable sideplates for protection Industry standard 3.85" x 3.85" footprint SpecificationsMounting: Surface OnlyVoltage: 48v DC (for 12-48v systems)Rating: 400 Cont / 600 Inter / 1500 CrankDims: 3.85" x 3.85" x 3.62"Operation: 1-2-Both-OffStud: 3x 10 mm (3.8")WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AFD: No Lockable: No Positions: 1-2-Both-Off Continuous Amperage: 400a Box Dimensions: 4"H x 7"W x 8"L WT: 1.2 lbs UPC: 843687007692 Owner's Manual (pdf)Brochure (pdf)

Read more less

1000A/50mV ShuntShunt 1000 Amp 50 mV - 1000A/50mV

Read more less

Lynx Smart BMS 500 M10 Battery Management SystemThe Lynx Smart BMS is a dedicated Battery Management System for Victron Lithium Smart Batteries. There are multiple BMS-es available for our Smart Lithium series of batteries, and the Lynx Smart is the most feature-rich and complete option. It is available in two versions: 500A and 1000A (both with M10 busbar connections).Features: Built-in 500A or 1000A contactor used as a fallback safety mechanism and also suitable as a remote controllable main system switch. Battery monitor, indicating state of charge percentage and more data. Pre-alarm signal: provide a warning before the system shuts down due to -for example- a low cell. Bluetooth for use with our VictronConnect app, for setup and monitoring, including Instant Readout - key data of the BMS at a glance. Local and remote monitoring using a Victron GX device, for example, the Cerbo GX or Ekrano GX. The Lynx Smart BMS is part of the modular Lynx Distribution system.VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

SmartSolar MPPT 450/100-MC4 VE.Can VE.Direct 450/100The SmartSolar MPPT RS solar charge controllers are Victron's solution for systems with large series connected PV arrays charging 48 V DC battery banks. This product is perfect for large off-grid, and grid-connected battery systems.In a 5.76kW and 11.52kW model, features include a wide 65-450 VDC operating solar voltage input, independent tracking inputs, full connectivity, isolated PV connections, a display screen, fully programmable battery charging parameters, and active cooling. The new metal case design and fully covered electrical connections improve safety and modernize the presentation in line with the latest suite of Victron products.MPPT: Ultra Fast Maximum Power Point TrackingThe SmartSolar RS solar charge controller connects to a PV array of between 65 and 450 Volt Voc and will efficiently charge your 48V battery bank with either 100A or 200A.The charge settings are fully programmable and can be set up for different battery chemistries, like lead-acid, lithium and more.Setup & monitor with VictronConnectThe SmartSolar RS charge controller can be remotely controlled and configured over Bluetooth via the VictronConnect app. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, historical data and trends.Daisy Chain Additional UnitsThe SmartSolar RS charge controller is equipped with VE.Can bus ports. This allows for communication with additional SmartSolar RS & VE.Can MPPT units. The additional units are simply “daisy chained” to each other with an RJ45 cable.When connected to each other, all individual charge controllers, will synchronise their charge stages. They can also send their data, via the same cable, for monitoring to a GX device (such as the Cerbo GX).Remote Monitoring and ControlIf the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your SmartSolar RS charge controllers.If your installation is connected to a GX device and the internet, Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; for free. For remote installations - even when there is no internet connection nearby - you may be able to monitor your MPPT by connecting the GlobalLink 520.SmartSolar DisplayThe SmartSolar RS charge controller is equipped with a display on the front panel. The display reads battery volts, charge current and voltages from both array’s individually including instantaneous and total figures and unit status including any possible error codes.I/O ConnectionsThe SmartSolar RS charge controller is equipped with a programmable relay and options for remote temperature and voltage sensing. The remote input can accept the Victron smallBMS and other types of BMS with allow-to-charge signals.  VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Please contact your dealer for any returns, repairs or support issues related to this product. Owner's Manual (pdf)Brochure (pdf)

Read more less

Argo Diode Battery Combiner - 80AMP - 2 BatteriesDiode Battery Combiners are used to guarantee continuous DC power to mission critical equipment, such as an electronic engine control system. With a Diode Battery Combiner two or more DC power sources can be used in parallel to supply the mission critical load. Failure of one source will not interrupt power to the critical load.Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

Spare Actuator Key f/8521 Battery Selector Switch

Read more less

4-Position Compact Dual Battery Selector SwitchThe 4-Position Battery Selector Switch is the ultimate solution for managing multiple battery banks in marine or RV electrical systems. Designed for 12V to 32V applications, this switch allows you to isolate battery banks, combine them, or direct power to all loads with a simple turn. Engineered with tin-plated copper studs, the switch ensures maximum conductivity and corrosion resistance for reliable long-term performance in harsh environments.This heavy-duty switch is IP66-rated for water resistance and features an ignition-protected design, meeting ISO 8846 and ABYC safety standards. The isolating cover with three snap-off side pieces protects rear contacts while allowing versatile wire access in any direction. With its robust one-piece terminal stud design and user-friendly operation, this battery switch is ideal for boats, RVs, and other off-grid applications requiring efficient power management.Features: Switches Between 4 Positions: Allows flexible power management by isolating battery banks, combining them, or directing power to all loads for maximum versatility. Tin-plated copper Studs: Provides exceptional conductivity and corrosion resistance, ensuring efficient operation in harsh marine or RV environments. Durable One-Piece Terminal Stud Design: Prevents loosening over time, ensuring a secure connection and stable performance for extended use. Isolating Cover with Snap-Off Sides: Protects rear contacts while allowing easy wire access from any direction, making installation quick and hassle-free. IP66 Water-Resistant Rating: Built to withstand powerful water jets, making it perfect for marine applications or environments exposed to moisture and dust. Meets Strict Safety Standards: Certified to ISO 8846 Marine Ignition Protection, ABYC, UL 1500, and SAE J1171, ensuring compliance with industry-leading safety requirements. Compact and Lightweight Design: Weighing just 0.83 lbs (0.38 kg), this switch is compact yet robust, saving space while delivering maximum performance. High Current Handling Capability: Rated for 300A continuous and 900A cranking, this switch is ideal for high-power applications like engine start and onboard systems. Specifications: Maximum Voltage: 32 VDC Switch Type: Selector 4-Position Battery Inputs: 1 Color: Red Cable Clearance for 4/0 AWG Cables: 1.12 in (28.45 mm) Cable Size to Meet Ratings: 4/0 AWG (120mm2) Switch Positions: 4 Battery Combine: Yes Alternator Field Disconnect: No Cranking Rating 30 seconds: 900A Continuous Rating: 300A Intermittent Rating: 500A (5 min) Mounting Holes: Accept #10 Screw Stud Material: Tinned Copper Stud Torque: 120 in-lb (13.56 Nm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 0.77 lbs (0.35 kg) Specifications: Continuous Amperage: 300 Positions: 4 Box Dimensions: 3"H x 3"W x 4"L WT: 0.7 lbs UPC: 817683023161 Brochure (pdf)

Read more less

On/Off Battery Disconnect SwitchThe Commodore On/Off Battery Disconnect Switch provides a reliable, durable, and safe solution for managing your marine or RV electrical systems. With a 300A continuous rating and a 900A cranking rating, this battery switch is designed to handle high-power applications, ensuring stable operation for your boat, RV, or off-grid systems. Its tin-plated copper studs offer superior conductivity and corrosion resistance, while the IP66-rated isolating cover provides robust protection against water and debris.This versatile switch can be surface-mounted or flush-mounted, with snap-off side pieces allowing wiring access from any direction. Designed to meet stringent marine safety standards, including ISO 8846 Marine Ignition Protection, this switch is a must-have for any professional or DIY marine electrical system. Built for durability and reliability, the CM-202S ensures your system stays safe and operational in even the harshest conditions.Features: High-Performance Ratings: Handles 300A continuous, 500A intermittent, and 900A cranking current, ensuring dependable performance for high-power marine or RV systems. Durable Tin-Plated Copper Studs: Features corrosion-resistant copper studs for maximum conductivity and long-lasting performance in harsh environments. Versatile Mounting Options: These can be surface-mounted or flush-mounted with snap-off side plates, offering flexible installation and clean cable management. Water-Resistant and Ignition Protected: Certified to ISO 8846 Marine standards, IP66-rated for protection against water jets, and safe for use in engine compartments. Easy Wire Access: The isolating cover includes three snap-off side pieces, allowing wiring from any direction while protecting rear terminals for enhanced safety. Meets Industry Standards: Complies with ABYC C-7, UL 1107, CSA C22.2 No.4, and other stringent safety regulations, ensuring compatibility and reliability. Compact and Lightweight Design: Weighing only 0.83 lbs (0.38 kg), the compact design saves space without compromising durability or performance. Rugged Marine-Grade Construction: Built to withstand the harshest marine and off-grid environments, ensuring long-lasting protection and reliable operation. Specifications: Maximum Voltage: 48 VDC Switch Type: Single Circuit On-Off Battery Inputs: 1 Color: Grey Cable Clearance for 4/0 AWG Cables: 1.12 in (28.45 mm) Cable Size to Meet Ratings: 4/0 AWG (120mm2) Switch Positions: 2 Battery Combine: No Alternator Field Disconnect: No Cranking Rating 30 seconds: 900A Continuous Rating: 300A Intermittent Rating: 500A (5 min) Mounting Holes: Accept #10 Screw Stud Material: Tinned Copper Stud Torque: 120 in-lb (13.56 Nm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 0.65 lbs (0.29 kg) Specifications: Continuous Amperage: 300 Positions: 2 Box Dimensions: 3"H x 3"W x 4"L WT: 0.57 lbs UPC: 817683023154 Brochure (pdf)

Read more less

Medium Duty Battery Selector Switches Diameter: 5-1/4" Depth: 2-5/8" Polycarbonate Body with Brass Terminals Ignition Protected For use with 6 to 32 Volt Marine Electrical Systems Capacity - 250 AMPS Continuous, 360 AMPS 5 Mins. Intermittent Terminal Stud Size: 5/16" When used with Non-Unitized Alternators, these models will interrupt the field current (reducing the possibility of damage) if turned "OFF" with the engine runnin Specifications: AFD: Yes Lockable: No Positions: 2 Continuous Amperage: 250a Box Dimensions: 3"H x 6"W x 8"L WT: 0.85 lbs UPC: 085226559969 Quick Guide (pdf)

Read more less

Orion-TR Smart 12/24-15A (360W) Isolated DC-DC Charger or Power SupplyThe Orion-Tr Smart isolated DC-DC charger serves as a DC-DC battery charger or a power supply (also designed for use as a constant voltage source), offering a wide input and output voltage range. This is especially significant in the case of vehicles with a Euro 5 or Euro 6 smart alternator, which often supplies too low charging voltage even when the engine is running or when extended cable lengths, as is often the case in boats and RVs, lead to voltage drops. In such scenarios, precise and controlled charging is imperative to fully charge the service battery while protecting the starter/input battery from discharge.Bluetooth Smart Enabled Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product Fully programmable Battery charge algorithm (configurable) or fixed output.  Smart Alternator Compatibility: engine running detection mechanism Adaptive 3-Stage Charge Algorithm: Bulk – Absorption – Float For lead-acid batteries, it is important that during shallow discharges the absorption time is kept short to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery is completely recharged For lithium batteries, the absorption time is fixed; the default is 2 hours Alternatively, a fixed output voltage can be chosen Suitable for Use in Vehicles with a Smart Alternator (Euro 5 and Euro 6 Engines)The built-in engine shutdown detection will stop the converter when the engine is not running. This prevents unwanted discharge of the starter battery (see manual for details).Remote On/OffA remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two-pole connector can be switched to battery minus (or the chassis of a vehicle, for example).All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.High Temperature ProtectedThe output current will reduce at high ambient temperatures.IP43 ProtectionWhen installed with the screw terminals oriented downward.Screw TerminalsNo special tools are needed for installation. Input fuse (not replaceable) *Input fuse (not replaceable) Specifications: Input Voltage Range: 10-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 24.2 V Output Voltage Adjust Range: 20-36 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 15 A Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 25 A Short Circuit Output Current: 40 A Cont. Output Power at 25 Degrees C: 430 W Cont. Output Power at 40 Degrees C: 360 W Efficiency: 88 % No Load Input Current (2): < 100 mA  Standby Current: Less than 1A Can Be Used as Power Supply: Yes, output voltage can be set with Bluetooth  Galvanic Isolation: 200 VDC between input, output, and case  Operating Temperature Range -20 to +55 °C (derate 3 % per °C above 40 °C)  Humidity: Max. 95 % non-condensing  DC Connection: Screw terminals  Maximum Cable Cross-Section: 16 mm²  AWG6  Weight: 1,8 kg (3 lb)  Dimensions (H x W x D):130 x 186 x 70 mm  (5.1 x 7.3 x 2.8 inch)  Protection Category IP43 (electronic components), IP22 (connection area)  Safety Standards: EN 60950 Emission/Immunity Standards: EN 61000-6-3, EN 55014-1 / EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Portable: No Charging Banks: 1 Charger Output Voltage: 24v Charger Output - Amps: 15a Charger Input - Voltage: 12v Box Dimensions: 4"H x 5"W x 8"L WT: 4.4 lbs UPC: 8719076047704 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Remote On/Off Key Switch f/701-MD & 720-MDO Battery SwitchesThe remote On/Off key switch is used for the remote operation of the 701-MD and 720-MDO battery switches. It can be mounted stand alone or within the Contour Connect panel range.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

M8 Circular Connector 3-Pole BMS BTV Extension Cables - Pair - 1MFeatures: 1-meter cable Extends the data cables that run from a 12.8 Volt Lithium-Ion battery to the BMS Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

BatteryProtect BP-65 - 65AMP - 6-35 VDCFeatures: The BatteryProtect disconnects the battery from non essential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.  12/24V auto ranging The BatteryProtect automatically detects system voltage  Programming made easy The BatteryProtect can be set to engage / disengage at several different voltages. The seven segment display will indicate which setting has been chosen.  A special setting for Li-ion batteries In this mode the BatteryProtect can be controlled by the VE.Bus BMS. Note: the BatteryProtect can also be used as a charge interrupter in between a battery charger and a Li-ion battery. See connection diagram in the manual.  Ultra low current consumption This is important in case of Li-ion batteries, especially after low voltage shutdown. Please see our Li-ion battery datasheet and the VE.Bus BMS manual for more information.  Over voltage protection To prevent damage to sensitive loads due to over voltage, the load is disconnected whenever the DC voltage exceeds 16V respectively 32V. Ignition proof No relays but MOSFET switches, and therefore no sparks. Delayed alarm output The alarm output is activated if the battery voltage drops below the preset disconnect level during more than 12 seconds. Starting the engine will therefore not activate the alarm. The alarm output is a short circuit proof open collector output to the negative (minus) rail, max. current 50 mA. The alarm output is typically used to activate a buzzer, LED or relay. Delayed load disconnect and delayed reconnect The load will be disconnected 90 seconds after the alarm has been activated. If the battery voltage increases again to the connect threshold within this time period (after the engine has been started for example), the load will not be disconnected. The load will be reconnected 30 seconds after the battery voltage has increased to more than the preset reconnect voltage. Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

SmartSolar MPPT 150/35 - 150V - 35AA solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.MPPT: Ultra Fast Maximum Power Point TrackingBy constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.Remote Monitoring and ControlRemotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

Smart BatteryProtect 48V - 100AThe Smart BatteryProtect disconnects the battery from non-essential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.When using Bluetooth to program the Smart BatteryProtect any required engage/disengage levels can be set. Alternatively, one of nine predefined engage/disengage levels can be set with the programming pin. If needed, Bluetooth can be disabled.The Smart BatteryProtect is a unidirectional device. It can only deal with current in one direction, so either current to a load, or current from a charger, but not both currents at the same time. In addition to this, current only can only flow from the IN terminal to the OUT terminal. In case of use with a load, the battery connects to the IN terminal, and in case of use with a charger, the charger connects to the IN terminal.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

BatteryProtect 48V - 100AThe BatteryProtect disconnects the battery from nonessential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.The BatteryProtect is a unidirectional device. It can only deal with current in one direction, so either current to a load, or current from a charger, but not both currents at the same time. In addition to this, current can only flow from the Battery terminal to the Load terminal. In case of use with a load, the battery connects to the Battery terminal, and in case of use with a charger, the charger connects to the Battery terminal.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

BCD 402 Combiner Diode - 2 Batteries - 40A BCD402Diode Battery Combiners guarantee continuous DC power to mission-critical equipment, such as an electronic engine control system. With a Diode Battery Combiner, two or more DC power sources can be used in parallel to supply the mission-critical load. Failure of one source will not interrupt power to the critical load.The Argo Battery Combiners feature a low voltage drop thanks to the use of Schottky diodes: at low current, the voltage drop is approximately 0,3 V, and at the rated output approximately 0,45 V.Warning: hot surface, mount the Argo Diode Battery Combiner on a non-flammable surface only!Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

SmartSolar MPPT 150/100-TR VE.CanThe MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges battery banks.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.MPPT: Ultra Fast Maximum Power Point TrackingThe MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium, and others.Control Your Charger RemotelyThe MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.Daisy Chain Additional UnitsThe VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply "daisy-chained" to each other with a single RJ45 cable between the individual units.When connected to each other, all individual VE.Can SmartSolar chargers, will synchronize their charge stages. They can also send their data, via a single cable, to a GX monitoring device.Remote Monitoring and ControlIf the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your solar charger(s).SmartSolar Control DisplayThe VE.Can SmartSolar charger is also equipped with a VE.Direct port like our other MPPT solar chargers. This port can be for single-unit monitoring or for streetlight control. The remote on/off connector can be externally controlled by a third-party device like a lithium battery. An optional plug-in LCD display/control provides live data, setup, and management, straight from the face of the device.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Filax 2 Transfer Switch 110V/50Hz-120V/60HzFilax: the ultra-fast transfer switch. The Filax has been designed to switch sensitive loads, such as computers or modern entertainment equipment from one AC source to another. The priority source typically is the mains, a generator, or shore power. The alternate source typically is an inverter. With its switching time of less than 20 milliseconds, sensitive loads will continue to operate without disruption. The Filax is not intended to supply high-power household equipment like washing machines or electric motors.Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

Lynx Smart BMS 1000 NG (M10) MGMT SystemThe Lynx Smart BMS NG is a dedicated Battery Management System (BMS) designed specifically for the Victron Lithium NG batteries. These batteries utilize Lithium Iron Phosphate (LiFePO4) technology and are available in 12.8 V, 25.6 V, and 51.2 V variants with various capacities. They can be configured in series, parallel, and series/parallel arrangements, allowing for the creation of battery banks with system voltages of 12V, 24V, or 48V. The maximum number of batteries in a single system is 50, enabling a maximum energy storage of 192kWh in a 12V system and up to 384kWh in a 24V and 48V system. For comprehensive details about these batteries, visit the Victron Lithium NG battery product page. Out of the various BMSes available* for the Lithium NG batteries, the Lynx Smart BMS NG is the most feature-rich and complete option and integrates seamlessly with other M10 products in the Lynx Distributor system. It is available in 500 A (M10) and 1000 A (M10) versions1).Built-in 500 A or 1000 A Contactor  Lynx Smart BMS NG 500A A Lynx Smart BMS NG 1000A  Available in 500 A (M10) and 1000 A (M10) versions Acts as a secondary safety system to protect the battery in case primary controls (ATC, ATD, and/or DVCC) fail Suitable as a remote controllable main system switch Pre-charge Circuit  Prevents high inrush currents when connecting capacitive loads like inverters Eliminates the need for external pre-charging devices Monitoring & Control  Bluetooth connectivity for monitoring and control via the VictronConnect App or VE.Can connectivity in combination with GX devices such as the Cerbo GX or Ekrano GX and the VRM portal Readout of cell voltages and temperatures also on GX devices and the VRM portal Built-in battery monitor provides data such as state of charge, voltage, current, historical data, status info, and more in real-time Diagnostic at a glance with Instant Readout DVCC Closed Loop Control as well as ATC/ATD Contacts  Compatible Victron inverter/chargers, the Orion XS 12/12-50A DC-DC battery charger, and solar charge controllers are automatically controlled via a connected GX device and DVCC. ATC/ATD contacts can be used to control other chargers and loads that have a remote on/off port Programmable Relay  Can be used either as an alarm relay (combined with the pre-alarm) or to control an alternator via its external regulator (ignition cable) Features Alternator ATC mode for safe alternator disconnection before battery disconnects AUX Terminal  Onboard auxiliary power supply (1.1 A @ system voltage) for powering specific loads (i.e. a GX device) post-BMS shutdown Automatic shutdown of BMS and AUX connection if no charge voltage is detected within 5 minutes after a low voltage event VE.Can and NMEA 2000 Data Communication  Easy connection and communication with GX devices via VE.Can using a standard RJ45 network cable Integration into marine networks via NMEA 2000 protocol (requires a VE.Can to NMEA 2000 micro-C male cable) Lynx Distributor Fuse Monitoring  Monitor fuse status of up to 4 connected Lynx Distributors via VictronConnect or GX devices Receive alarms in case of blown fuses 1) Up to 5 BMS-es can be paralleled. This requires a firmware update, expected in Q3 2024.SpecificationsPower: Battery Voltage Range: 9 – 60 VDC  Maximum Input Voltage: 75 VDC  Supported System Voltages: 12, 24, or 48 V  Reverse Polarity Protection: No  Main Safety Contactor Continuous Current Rating: 1000 A continuous  Main Safety Contactor Peak Current Rating: 1200 A for 5 minutes Power Consumption OFF Mode: 0.3 mA for all system voltages  Power Consumption in Standby Mode: Approximately 0.6 W (50 mA at 12 V)  Power Consumption in ON Mode: Approximately 4.2 W (350 mA at 12 V) depending on the state of the relays Minimum Load Resistance for Pre-Charging: 10 Ω and above for 12 V systems 20 Ω and above for 24 V and 48 V systems  AUX Output Maximum Current Rating: 1.1 A continuous, protected by resettable fuse  Allow-to-Charge Port Maximum Current Rating: 0.5 A at 60 VDC, protected by resettable fuse  Allow-to-Discharge Port Maximum Current Rating: 0.5 A at 60VDC, protected by resettable fuse Alarm Relay (SPDT) Maximum Current Rating: 2 A at 60 VDC Connections: Busbar: M10 (Torque: 33 Nm) – can be combined with all M10 Lynx products  VE.Can: RJ45  I/O: Removable multi-connector with screw terminals  Battery BTV Cables: Male and female circular 3-pole connector with M8 screw ring Up to 50 batteries can be connected in one system  Lynx Distributor Fuse Monitoring (up to 4 modules): RJ10 (cable ships with each Lynx Distributor) Physical: Enclosure Material: ABS  Enclosure Dimensions (H x W x D): 230 x 180 x 100 mm Unit Weight: 2.7 kg  Busbar Material: Tinned copper  Busbar Dimensions (H x W): 8 x 30 mm Environmental: Operating Temperature Range: -40 °C to +60 °C  Storage Temperature Range: -40 °C to +60 °C  Humidity: Max. 95 % (non-condensing)  Protection Class: IP22 Standards: Safety: EN-IEC 63000:2018  EMC: EN-IEC 61000-6-3:2007/A1:2011/AC:2012  QMS: NEN-EN-ISO 9001:2015 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

BlueSolar PWM-Light Charge Controller - 12/24V - 20AMPFeatures: Load output with low battery voltage disconnect function. Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable. Load output protected against over load and short circuit. Protected against reverse polarity connection of the solar array and/or battery. Day/night timing options: see manual for details Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

60 AMP MPPT Charge ControllerEnhanced Energy Optimization & SmartSolar Performance.The Xantrex Solar Charger Controller MPPT60 delivers superior efficiency and performance, supporting up to 150V and 60A for optimal power harvesting and seamless scalability in your solar system. Featuring advanced Maximum Power Point Tracking (MPPT) technology, it offers up to 30% more power compared to PWM charge controllers, enhancing overall energy efficiency. Compatible with 12V, 24V, 36V, and 48V battery systems, the MPPT60 optimizes performance across various energy requirements. This controller provides real-time energy monitoring and comprehensive historical data, empowering informed decisions for improved system performance, energy savings, and reliability.Features: Ultra-fast tracking speed including multiple power point peaks with a 99.5% efficiency rating Xantrex MPPT control algorithm maximizes solar system efficiency and energy harvesting effectiveness Manages and optimizes power output from a diverse array of solar panels under varying environmental conditions Regulates power and current flow to protect and prolong battery lifespan The battery’s status is monitored, and the charging current is adjusted to prevent overcharging when fully charged Protection against short-circuiting enhances safety, while protection against input overloading enhances system reliability and longevity Battery temperature compensation boosts both system performance and charging efficiency Real-time monitoring provides data on energy usage and solar power system efficiency Dynamic power reduction prevents overheating and improves battery performance and safety Specifications: LED indicators display PV charging, charger stage, and event status Remote panel for monitoring and setting (requires the Solar MPPT Remote Panel) 30% Higher than the PWM load RV short-circuit protection, charge over-current protection RV-C, Modbus, and Bluetooth built-in 12/24/36/48V System Voltage MPPT tracking efficiently is up to 99.5% Lead-acid, AGM (Sealed), Gel, Flooded, Lithium batteries and custom Current-limiting charging mode Xantrex App for ultimate control Compliance: UL1741CSA C22.2#107.1

Read more less

Lynx Smart BMS 500 NG (M10)The Lynx Smart BMS NG is a dedicated Battery Management System (BMS) designed specifically for the Victron Lithium NG batteries. These batteries utilize Lithium Iron Phosphate (LiFePO4) technology and are available in 12.8 V, 25.6 V, and 51.2 V variants with various capacities. They can be configured in series, parallel, and series/parallel arrangements, allowing for the creation of battery banks with system voltages of 12V, 24V, or 48V. The maximum number of batteries in a single system is 50, enabling a maximum energy storage of 192kWh in a 12V system and up to 384kWh in a 24V and 48V system. For comprehensive details about these batteries, visit the Victron Lithium NG battery product page. Out of the various BMSes available* for the Lithium NG batteries, the Lynx Smart BMS NG is the most feature-rich and complete option and integrates seamlessly with other M10 products in the Lynx Distributor system. It is available in 500 A (M10) and 1000 A (M10) versions1).Built-in 500 A or 1000 A Contactor  Available in 500 A (M10) and 1000 A (M10) versions Acts as a secondary safety system to protect the battery in case primary controls (ATC, ATD, and/or DVCC) fail Suitable as a remote controllable main system switch Pre-Charge Circuit  Prevents high inrush currents when connecting capacitive loads like inverters Eliminates the need for external pre-charging devices Monitoring & Control  Bluetooth connectivity for monitoring and control via the VictronConnect App or VE.Can connectivity in combination with GX devices such as the Cerbo GX or Ekrano GX and the VRM portal Readout of cell voltages and temperatures also on GX devices and the VRM portal Built-in battery monitor provides data such as state of charge, voltage, current, historical data, status info, and more in real-time Diagnostic at a Glance with Instant Readout DVCC Closed Loop Control as well as ATC/ATD Contacts  Compatible Victron inverter/chargers, the Orion XS 12/12-50A DC-DC battery charger, and solar charge controllers are automatically controlled via a connected GX device and DVCC. ATC/ATD contacts can be used to control other chargers and loads that have a remote on/off port Programmable Relay  Can be used either as an alarm relay (combined with the pre-alarm) or to control an alternator via its external regulator (ignition cable) Features Alternator ATC mode for safe alternator disconnection before battery disconnects AUX Terminal  Onboard auxiliary power supply (1.1 A @ system voltage) for powering specific loads (i.e. a GX device) post-BMS shutdown Automatic shutdown of BMS and AUX connection if no charge voltage is detected within 5 minutes after a low voltage event VE.Can and NMEA 2000 Data Communication  Easy connection and communication with GX devices via VE.Can using a standard RJ45 network cable Integration into marine networks via NMEA 2000 protocol (requires a VE.Can to NMEA 2000 micro-C male cable) Lynx Distributor Fuse Monitoring  Monitor fuse status of up to 4 connected Lynx Distributors via VictronConnect or GX devices Receive alarms in case of blown fuses 1) Up to 5 BMS-es can be paralleled. This requires a firmware update, expected in Q3 2024.SpecificationsPower: Battery Voltage Range: 9 – 60 VDC  Maximum Input Voltage: 75 VDC  Supported System Voltages: 12, 24, or 48V  Reverse Polarity Protection: No  Main Safety Contactor Continuous Current Rating: 500 A continuous  Main Safety Contactor Peak Current Rating: 600 A for 5 minutes  Power Consumption OFF Mode: 0.3 mA for all system voltages  Power Consumption in Standby Mode: Approximately 0.6 W (50 mA at 12 V)  Power Consumption in ON Mode: Approx. 2.6 W (217 mA at 12 V) depending on the state of the relays  Minimum Load Resistance for Pre-Charging: 10 Ω and above for 12 V systems 20 Ω and above for 24 V and 48 V systems  AUX Output Maximum Current Rating: 1.1 A continuous, protected by resettable fuse  Allow-to-Charge Port Maximum Current Rating: 0.5 A at 60 VDC, protected by resettable fuse  Allow-to-Discharge Port Maximum Current Rating: 0.5 A at 60VDC, protected by resettable fuse Alarm Relay (SPDT) Maximum Current Rating: 2 A at 60 VDC Connections: Busbar: M10 (Torque: 33 Nm) – can be combined with all M10 Lynx products  VE.Can: RJ45  I/O: Removable multi-connector with screw terminals  Battery BTV Cables: Male and female circular 3-pole connector with M8 screw ring Up to 50 batteries can be connected in one system  Lynx Distributor Fuse Monitoring (up to 4 modules): RJ10 (cable ships with each Lynx Distributor) Physical: Enclosure Material: ABS  Enclosure Dimensions (H x W x D): 190 x 180 x 80 mm  Unit Weight: 1.9 kg  Busbar Material: Tinned copper  Busbar Dimensions (H x W): 8 x 30 mm Environmental: Operating Temperature Range: -40 °C to +60 °C  Storage Temperature Range: -40 °C to +60 °C  Humidity: Max. 95 % (non-condensing)  Protection Class: IP22 Standards: Safety: EN-IEC 63000:2018  EMC: EN-IEC 61000-6-3:2007/A1:2011/AC:2012  QMS: NEN-EN-ISO 9001:2015 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Cyrix-Li-ct 12/24V-230A Intelligent Li-Ion Battery CombinerThe Cyrix Battery Combiner is a microprocessor controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged), and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is virtually no voltage loss, so the output voltage of alternators or battery chargers does not need to be increased.The functionality of the Cyrix-Li-ct is analogous to the Cyrix-ct.The Cyrix-Li-ct will parallel connect a lead acid starter battery and a LiFePO4 battery: If the charge disconnects the output of the VE.Bus BMS is high, and If it senses 13,4 V (resp. 26,8 V) or more on one of its power terminals. The Cyrix will disengage immediately: When its control output becomes free floating, signaling cell over voltage or cell over temperature, and when battery voltage drops below 13,2 V Start assist function: a short negative pulse will close the relay for 30 seconds A built-in transient voltage suppressor will limit the voltage spike that may occur when the Cyrix suddenly disengages due to cell overvoltage or over-temperature Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

BMV-700 Battery MonitorThe BMV-700 is a high precision battery monitor. The essential function of a battery monitor is to calculate ampere hours consumed and the state of charge of a battery. Ampere hours consumed are calculated by integrating the current flowing in or out of the battery.Features: Battery voltage, current, power, ampere-hours consumed and state of charge  Remaining time at the current rate of discharge  Programmable visual and audible alarm  Programmable relay, to turn off non critical loads or to run a generator when needed  500 Amp quick connect shunt and connection kit  Shunt selection capability up to 10.000 Amps  VE.Direct communication port  Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health  Wide input voltage range: 6,5 – 95V  High current measurement resolution: 10 mA (0,01A)  Low current consumption: 2,9Ah per month (4mA) @12V and 2,2Ah per month (3mA) @ 24V VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less
