A295 Dual Payload 384x288 Thermal + 1080P (10x Zoom) Visible Spectrum IP PTZ CameraThe IRIS-A295 Low-Cost Dual Payload Night Vision PTZ From Iris Innovations.With an industry-leading 400×300 thermal resolution, the cameras also feature a 2MP high-definition visible spectrum camera core with excellent low light performance, super sharp footage, and 10x optical zoom capabilities.Available with side entry or base entry cable options, the cameras are built into a robust yet compact waterproof case, designed to protect the unit from the harshest environmental conditions.Each sensor has its IP address meaning the cameras can be configured, controlled, and switched independently, and are compatible with many leading marine chart plotters via our range of CMAC camera management interfaces. An RS485 Serial Data connection is also provided to maximize control options so Atom cameras can be controlled using suitable joystick control devices and NVRs. With its rugged, compact footprint and extremely competitive pricing, our ATOM range of IP PTZ cameras is the perfect solution for vessels of all types and sizes and our industry-leading thermal imaging technology opens up a world of boating at night in safety. Standing only 8″ high, ATOM cameras blend into the vessel's aesthetic without standing out, and because they are so small they are the perfect camera solution for RIBs, center consoles, and sports fishing boats.To maximize compatibility, the ATOM-A295 is both ONVIF compliant and as the camera is also NDAA compliant, can be used for government, military, and other security-sensitive applications.Features: Dual Spectrum Cameras - Thermal & Visible Spectrum Visible Spectrum Camera 2MP HD Resolution 10x Optical Zoom 384x288 (A295) thermal core resolution - 4x Digital Zoom Miniature - Lightweight Compact Form Factor Dimensions 206mm x 160mmø / 2Kg Weight Available with single IP address or dual IP addresses Side mount or Rear mount Waterproof Cable Connector Push Lock Quick Connector - IP66 17µm Pixel Pitch Features IP and RS485 Serial Data Control 750mA @ +12VDC Power / 8.4W IP66 Environmental Rating Technical Specifications: Thermal Camera Resolution - 384x288 Thermal Camera Lens - 19mm Pixel Pitch - 17µm Refresh Rate - 25/30Hz Color Pallets - White Hot / Black Hot / Fulgurite / Iron Red / Hot Iron / Medical / Arctic / Rainbow 1 / Rainbow 2 / Tint Image Enhancement - ICE® Image Contrast Enhancement - 7 Levels Zoom - x4 Smooth Digital Zoom - Continuous Visible Spectrum Camera - 1/2.8” High-Performance Low Illumination SONY CMOS Sensor IMX327 Resolution - 1920 x 1080 25/30 frames/sec Focal Length / Iris / Zoom - F = 4.7mm 94mm / F1.6 F3.5 / 20x Optical Zoom Compression - H.264 / H.265 Bit Rate - 32Kbps 16Mbps Frame Rate - 1-25fps(50Hz) / 1-30fps(60Hz) Streams - Supports dual stream, main stream (1080P; 960P; 720P), Sub Stream (D1; VGA; CIF) Cellular/WiFi/GPS - Optional Protocols - Network Protocols: ONVIF Profile S / Others TBC Serial Data: RS485 / Pelco D Power Requirements - +12vDC / 750mA / 8.4W Quick Guide (pdf)Owner's Manual (pdf)

Read more less

ATOM A418 2MP IP HD PTZ Camera/Single Payload Low Light with IR LED + 30x Optical ZoomThe Atom Range, A418 High Definition Visible Spectrum IP PTZ camera with 30x Optical Zoom from Iris Innovations. Available with side entry or base entry cable options, the A418’s high-definition camera module is built into a robust yet compact waterproof gimbal mount enclosure, designed to protect the unit from the harshest environmental conditions. The A418 features a high-end network camera module with leading digital image processing features such as noise reduction, image enhancement, and wide dynamic range technology and boasts a powerful 30x optical zoom lens to identify targets at extreme distances.An array of high-power infrared LED illuminators is built into the brow of the camera to provide visibility in the dark to a range of up to 100 meters. The camera's image processing features work to boost the image gain in order to provide maximum clarity in low light.As well as offering ultra-responsive pan and tilt control with proportional zoom operation, the camera boasts up to 255 user-preset positions and a range of scans and user-configurable automated tours. An RS485 Serial Data connection is also provided to maximize control options, meaning as well as via an NVR or computer, the camera can also be controlled from Iris’s CMAC range of camera management systems or CCTV joystick controllers supporting the Pelco-D protocol. With its rugged, compact footprint and extremely competitive pricing, the IP PTZ cameras are the perfect solution for vessels of all types and sizes and our industry-leading thermal imaging technology opens up a world of boating at night in safety. The A418 camera is both ONVIF compliant and NDAA compliant.Features: Visible Spectrum Camera 2MP HD Resolution 30x Optical Zoom Miniature - Lightweight Compact Form Factor Dimensions 206mm x 160mmø / 2Kg Weight High Power Infrared LEDs - Up to 80m Range True Day/Night Operation with IR Cut Switch Up to 255 User Presets Supported 4 x User Definable Patrols User Definable Home Position Side mount or Rear mount Waterproof Cable Connector Push Lock Quick Connector - IP66 Features IP and RS485 Serial Data Control 750mA @ +12VDC Power / 8.4W IP66 Environmental Rating Available in White, Black & Other Color Options Technical Specifications: Camera Resolution - 1920 x 1080P 2MP 25/30 frames/sec Sensor - 1/2.8” High-Performance Low Illumination CMOS Sensor (IMX327) Focal Length - 4.7mm 141mm Image Enhancement - DWDR IR Range - 4 x High Powered Infrared Lamps, 2 Groups (Low Beam / High Beam) Brown Glass Filter, Infrared Distance up to 100m (328ft) Park Function - Supported Video Format - AVI D1/720P/1080P (default) Snapshot Storage - Optional - D1/720P/1080P (default) Compression - H.264 / H.265 Bit Rate - 32Kbps 16Mbps Frame Rate - 1-25fps(50Hz) / 1-30fps(60Hz) Streams - Supports dual stream, main stream (1080P; 960P; 720P), Sub Stream (D1; VGA; CIF) Cellular/WiFi/GPS - Optional Protocols - Network Protocols: ONVIF Profile S / Others TBC Serial Data: RS485 / Pelco D Power Requirements - +12vDC / 2000mA Max (IR ON) / 24W Max Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Fish-Scout Predator Color Underwater Camera with Multi ViewThis FS4000P is an underwater camera paired with a monitor & HDMI interface. Also, the underwater camera has multiple viewing angles.System Includes: 5" monitor unit with fixed cable management spool and rubber stopper Built-in Li-polymer battery HD camera with temperature and direction, plus viewing angle adjustment 50-foot camera cable with 1' depth marks Over-hole suspension arm with built-in compass 5V 3A power cube adapter 40" USB-A to USB-C power cable 6" HDMI adapter cable (micro-HDMI to HDMI) MiniSD slot for saving pictures and recording videos (SD card not included) Protective soft-pack carry case ¼"×20 inserts on the top, bottom, and back of the monitor unit Strap-loop lanyard Specifications: 1080p Sony® camera 1280×720 Monitor Connects to any TV or monitor with an HDMI port Patent-pending adjustable camera with five viewing angles: 0° horizontal, 45° up, 90° up, 45° down, and 90° down. Camera lights: two LEDs and two IR Water temperature is accurate within 1 degree Direction sensor displays: N, NE, E, SE, S, SW, or W Current draw: 1.24A @ 3.7V (4.75W) Total system weight of 3.0 pounds Brochure (pdf)

Read more less

JCU-2 Joystick ControllerThe joystick is the primary control for the M400 & M400XR and the M300 series (M300C, M332, M364, M364C, and M364C LR. It is used to wake the system or put it in standby, operate the pan and tilt movement, zoom the camera, control cameras modes and features, and configure system settings by means of OSD menus.Includes: Includes: JCU-2 keypad Keypad mat Mounting gasket 4 x mounting screws, rubber washers, mounting clamps Cable gland nut RJ45-to-RJ45 Ethernet cable, 7.6 m (25 ft) Documentation pack

Read more less

Fish-Scout Base Camp Underwater CameraThe Fish-Scout® Base Camp is an underwater video camera with HDMI interface.System Includes: HD camera with temperature and direction, plus viewing angle adjustment Control box with HDMI video out 50-foot camera cable with depth marks Cable management spool with rubber stopper Over-hole suspension arm with built-in compass 5V 3A power cube adapter 10’ USB-A to USB-C power cable 10’ HDMI weatherproof cable Protective soft pack carry case with strap Stainless steel mounting screws Specifications: 1080p Sony® camera Connects to any TV or monitor with an HDMI port (monitor not included) Patent pending adjustable camera with five viewing angles: 0° horizontal, 45° up, 90° up, 45° down and 90° down Camera lights: two LEDs and two IR Water temperature is accurate within 1 degree Direction sensor displays: N, NE, E, SE, S, SW or W Water resistant control box: IP65 rating 750mA current draw Total system weight of 2.97 pounds Brochure (pdf)

Read more less

Free Standing MountFLIR Free Standing Mount for FLIR's AX8™ and Raymarine Dragonfly 4/5/7.

Read more less

Nitron XD Night Vision Camera - White Housing - Tall MountThe Nitron XD Marine Night Vision Camera displays the highest resolution possible, giving users crystal clear imagery in pitch black darkness. Without relying on thermal temperatures, users will have the perfect HD image in any nighttime condition.  Boasting an IP69K rating, the Nitron XD can withstand the harshest environments. With the ability to connect right into a Garmin, Simrad, Raymarine, or many other monitors, installing Black Oak's marine video camera is practically plug-n-play. With the included cable, plug right into a video input port.*This version is the tall mount version Hyper-Low Lux SensorNitron XD was specifically designed to function in complete darkness, providing crystal-clear HD video in any nighttime environment, no matter the ambient temp.2X The ResolutionSee more than just silhouettes; Nitron XD shows details in full HD.Marine RatedThis Black Oak' camera can withstand heavy spray and handle immersion up to 3 feet for over 60 hours.Easy InstallationBlack Oak includes everything needed to easily install, along with a plug-and-play harness to fully integrate with a MFD.Plug-N-Play with MFD Easily connect to a Garmin, Simrad, or other popular MFD with the supplied brand specific video input cable. See why Black Oak is the #1 night vision camera for boating.Do it at NightTurn night into day and achieve peace of mind with the ability to see channel markers, boats, buoys, and other hazardous objects.Built to LastWith Black Oak's military-grade housing, there is no need to worry about this camera withstanding the harsh marine environments. Black Oak's camera is designed to handle any salt, corrosion, humidity, or moisture users throw at it.Quick ConnectTake advantage of Black Oak's easy-access quick connect harness. With the ability to easily remove or attach, users never have to worry about leaving this camera.Features: .0000025 Lux starlight night vision Two field of view options: 20 or 30 degrees Streams 752 x 582 HD video 60 frames per second Marine grade waterproof housing Connect directly to a MFD Flexible installation (top or bottom mount) 12Vdc power (fused) NTSC/PAL analog video connection (BNC) Manual vertical tilt adjustment Marine grade IP69K waterproof housing Technical Specifications: Hyper Low Lux: .0000025 HD Resolution: 752(H) x 582(V) Power Consumption: 1.38 Watts  Frame Refresh Rate: 60 frames per second  Noise Reduction: 3DNR Length (front to end): 8-3/16” Height (top to bottom): 9” In the Box: Nitron XD Marine Camera System 25' quick connect wiring harness 5A inline fuse Anodized aluminum mounts *Sold as an Individual Specifications: Reverse Image: Yes Box Dimensions: 7"H x 10"W x 12"L WT: 4 lbs UPC: 850044517541 Owner's Manual (pdf)

Read more less

Nitron XD Night Vision Camera - White Housing - Standard MountThe Nitron XD Marine Night Vision Camera displays the highest resolution possible, giving users crystal clear imagery in pitch black darkness. Without relying on thermal temperatures, users will have the perfect HD image in any nighttime condition.  Boasting an IP69K rating, the Nitron XD can withstand the harshest environments. With the ability to connect right into a Garmin, Simrad, Raymarine, or many other monitors, installing Black Oak's marine video camera is practically plug-n-play. With the included cable, plug right into a video input port.*This version is the standard mount version Hyper-Low Lux SensorNitron XD was specifically designed to function in complete darkness, providing crystal-clear HD video in any nighttime environment, no matter the ambient temp.2X The ResolutionSee more than just silhouettes; Nitron XD shows details in full HD.Marine RatedThis Black Oak' camera can withstand heavy spray and handle immersion up to 3 feet for over 60 hours.Easy InstallationBlack Oak includes everything needed to easily install, along with a plug-and-play harness to fully integrate with a MFD.Plug-N-Play with MFD Easily connect to a Garmin, Simrad, or other popular MFD with the supplied brand specific video input cable. See why Black Oak is the #1 night vision camera for boating.Do it at NightTurn night into day and achieve peace of mind with the ability to see channel markers, boats, buoys, and other hazardous objects.Built to LastWith Black Oak's military-grade housing, there is no need to worry about this camera withstanding the harsh marine environments. Black Oak's camera is designed to handle any salt, corrosion, humidity, or moisture users throw at it.Quick ConnectTake advantage of Black Oak's easy-access quick connect harness. With the ability to easily remove or attach, users never have to worry about leaving this camera.Features: .0000025 Lux starlight night vision Two field of view options: 20 or 30 degrees Streams 752 x 582 HD video 60 frames per second Marine grade waterproof housing Connect directly to a MFD Flexible installation (top or bottom mount) 12Vdc power (fused) NTSC/PAL analog video connection (BNC) Manual vertical tilt adjustment Marine grade IP69K waterproof housing Technical Specifications: Hyper Low Lux: .0000025 HD Resolution: 752(H) x 582(V) Power Consumption: 1.38 Watts  Frame Refresh Rate: 60 frames per second  Noise Reduction: 3DNR Length (front to end): 8-3/16” Height (top to bottom): 6” In the Box: Nitron XD Marine Camera System 25' quick connect wiring harness 5A inline fuse Anodized aluminum mounts *Sold as an Individual Specifications: Reverse Image: Yes Box Dimensions: 7"H x 10"W x 12"L WT: 3.75 lbs UPC: 850044517350 Owner's Manual (pdf)

Read more less

GTX100 Scion Docking StationMounts easily to surfaces, its built-in locking feature latches the Scion thermal monoculars securely in place even during prolonged vibration and abrupt maneuvering. When powered, the station also charges the GPX310 rechargeable batteries while the Scion is docked.Specifications: Connector Type: USB-C to USB-C Locking System: Auto-lock with push-button release Security: Security lockout for long term storage Mounting: 3-point bulkhead mount Tripod Mount: 1/4-20 tripod mounting point Environmental: IP56-rated Operating Temperature: -22 to 104°F (-30 to 40°C)  Storage Temperature: -40 to 158°F (-40 to 70°C) Quick Guide (pdf)
