5120 350AMP Class T FuseFeatures: Extremely fast short-circuit response 20,000 Ampere Interrupt Capacity (AIC) UL listed to standard 248-15 DC Tested to UL standard 198L WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 350a Fuse Type: Class T Type: Fuses Box Dimensions: 2"H x 4"W x 6"L WT: 0.3 lbs UPC: 632085051204

Read more less

5107 MEGA®/AMG® Fuse - 250AMPFeatures: Most economical fuse for 100-300 Ampere circuit protection For use with Blue Sea Systems' MEGA®/AMG® Fuse Block WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 250a Fuse Type: MEGA/AMG Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.03 lbs UPC: 632085051075

Read more less

MAXI® In-Line Fuse HolderFeatures: Supplied with #6 red lead wire, 5" length 32V DC Max. voltage rating 60A Max. fuse amperage Firewall mounting hole permits: Two or more holders to be mounted together Surface mount Cover comes with a removable strap Fuse sold separately WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: MAXI Type: Fuse Holders Box Dimensions: 2"H x 4"W x 8"L WT: 0.4 lbs UPC: 632085050689

Read more less

Fuse MIDI/AMI 50A - PairFeatures: Compact fuse with 50A amperage Tin-plated copped for corrosion resistance Clear cover offers visible indication of blown fuses Color-coded for easy amperage identification Ignition protected to SAE J1171 when used with Blue Sea Systems SafetyHub family of products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Fuse Type: MIDI/AMI Type: Fuses Box Dimensions: 1"H x 2"W x 3"L WT: 0.05 lbs UPC: 632085052522 Brochure (pdf)

Read more less

5135ANL Fuse350A Ignition protected (conforming to SAE J1171)- safe for installation aboard gasoline powered boats Silver-plated connector blades for corrosion resistance Visible indication of blown condition 6,000 Ampere Interrupt Capacity (AIC) satisfies ABYC requirements for main DC circuit protection on large battery banks For use with Blue Sea Systems' ANL Fuse Blocks WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 350a Fuse Type: ANL Type: Fuses Box Dimensions: 2"H x 4"W x 6"L WT: 0.2 lbs UPC: 632085051358

Read more less

5116 200A Class T FuseFeatures: Extremely fast short-circuit response 20,000 Ampere Interrupt Capacity (AIC) UL listed to standard 248-15 DC Tested to UL standard 198L WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 200a Fuse Type: Class T Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.15 lbs UPC: 632085051167

Read more less

ANL Fuse Holder with 2 Additional Studs, 750AProviding high-capacity fusing, fast response and very high interrupt ratings (ANL up to 6,000 Amps, Class-T up to 20,000 Amps), these fuse holders are ideal for protecting today's demanding onboard power electronics technology including inverters and battery chargers. They also protect wiring from short circuits. Pro Installer fuse holders' durable construction allow fuses to run at maximum load. Radiused ends improve cable routing options ANL: for use with 5/16" (8mm) or 3/8" (10mm) ANL fuses WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ANL Type: Fuse Blocks Box Dimensions: 2"H x 7"W x 8"L WT: 0.9 lbs UPC: 843687006794 Brochure (pdf)

Read more less

RT Fuse Block 6 Position with LED IndicationThis 6-position fuse block has a modular design that can produce seven (7) unique configurations from Egis 8028 & 8030 and reduce part numbers to stock for all build requirements. Also, this fuse block has an LED indication.Applications: Blown fuse LEDs speed up the correction of system faults and improve the ability to remotely diagnose customer issues. Harsh environment design with stainless steel self-locking hardware and optional weather-proof labels in standard or customized options. Features: Bullet-proof construction - designed with high-temperature materials and stainless steel self-locking hardware allows mounting anywhere on the vehicle Protects branch circuits by accepting ATO style fuses ranging from 1 through 40 Amps Supports SAE circuit protection standards for thermal/short circuit events Specifications: Maximum Current (Entire Block) Amps: 100 Maximum Current (Per Circuit) Amps: 30 Max Output Wire Size: #10 AWG Voltage Range VDC: 0-36 Number of Fuse Positions: 6 Compatible Fuse Types: ATO / ATC / ATF Focal Features:Spare Fuse LocationsTwo locations per 6 circuits for spare or test resistors to reduce siren volumes during evaluation.Stainless Steel Self-Locking Hardware100 % non-ferrous corrosion-resistant materials. All attachment screws and nuts are self-locking.LED Fuse DiagnosticsBlown fuse LED indication for each output circuit provides a clear indication of faulty circuits and eases troubleshooting issues remotely.Cover/ Label RecessesProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 100a Fuse Type: ATO/ATC/ATF Type: Fuse Blocks Box Dimensions: 3"H x 3"W x 5"L WT: 0.5 lbs UPC: 850035199732 Quick Guide (pdf)

Read more less

Lynx Power-In with M10 TerminalsThe Lynx Power In contains a positive and negative busbar with 4 connections for batteries, loads, or chargers and a ground connection. It is part of the Lynx Distribution System. This version is a M10 busbar.Note that M10 refers to the busbar connection joints where the modules are connected. The fuse and cable connections are always M8.The Lynx Distribution SystemThe Lynx Distribution System is a modular busbar system that incorporates DC connections, distribution, fusing, and battery monitoring and/or lithium battery management. The Lynx Distribution System Consists of the Following PartsLynx Power InA positive and negative busbar with four batteries or DC equipment connections.Lynx DistributorA positive and negative busbar with four fused connections for batteries or DC equipment and fuse monitoring, is available in two versions.Lynx Shunt VE.CanA positive busbar with a space for a main system fuse and a negative busbar with a shunt for battery monitoring. It has VE.Can communication for monitoring and setup with a GX device.Lynx Smart BMSFor use together with Victron Energy Smart Lithium batteries. It contains a positive busbar with a contactor driven by a battery management system (BMS) and a negative busbar with a shunt for battery monitoring.It has Bluetooth communication for monitoring and setup via the VictronConnect App and VE.Can communication for monitoring with a GX device and the VRM portal. Available as a 1000A model with M10 busbars.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

ATO/ATC Fuse HolderWatertight, extra heavy duty and weatherproof. For use with fuses up to 30 Amps. 12 gauge wire leads for easy hook-ups. Fuse not included.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Holders Box Dimensions: 2"H x 3"W x 7"L WT: 0.1 lbs UPC: 022697143488

Read more less

5127ANL Fuse150A Ignition protected (conforming to SAE J1171)- safe for installation aboard gasoline powered boats Silver-plated connector blades for corrosion resistance Visible indication of blown condition 6,000 Ampere Interrupt Capacity (AIC) satisfies ABYC requirements for main DC circuit protection on large battery banks For use with Blue Sea Systems' ANL Fuse Blocks WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 150a Fuse Type: ANL Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.05 lbs UPC: 632085051273

Read more less

MIDI-Fuse 50A/58V-M6 (Package of 5)Victron Energy's MIDI fuses are essentially a smaller version of the MEGA fuses, which are known for their low voltage drop and cold resistance. This particular pack of Victron MIDI fuses contains five 100-amp fuses.Specifications: Max Current Rating: 50 amps Max Voltage Rating: 58 volts Approximate Voltage Drop: 65 mV Cold Resistance: 2 mΩ Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

5031ST Blade Fuse Block w/out Cover - 12 Circuit w/ Negative Bus Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit Accepts ATO and ATC fast acting blade fuses WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Blocks Box Dimensions: 2"H x 4"W x 10"L WT: 0.7 lbs UPC: 632085050313 Owner's Manual (pdf)

Read more less

RT Fuse Block 6 Position with Ground & LED IndicationThis 6-position fuse block has a modular design that can produce seven (7) unique configurations from Egis 8028 & 8030 and reduce part numbers to stock for all build requirements. Also, this fuse block has a ground and LED indication.Applications: Blown fuse LEDs speed up the correction of system faults and improve the ability to remotely diagnose customer issues. Harsh environment design with stainless steel self-locking hardware and optional weather-proof labels in standard or customized options. Features: Bullet-proof construction - designed with high-temperature materials and stainless steel self-locking hardware allows mounting anywhere on the vehicle Protects branch circuits by accepting ATO style fuses ranging from 1 through 40 Amps Supports SAE circuit protection standards for thermal/short circuit events Specifications: Maximum Current (Entire Block) Amps: 100 Maximum Current (Per Circuit) Amps: 30 Max Output Wire Size: #10 AWG Voltage Range VDC: 0-36 Number of Fuse Positions: 6 Compatible Fuse Types: ATO / ATC / ATF Focal Features:Spare Fuse LocationsTwo locations per 6 circuits for spare or test resistors to reduce siren volumes during evaluation.Stainless Steel Self-Locking Hardware100 % non-ferrous corrosion-resistant materials. All attachment screws and nuts are self-locking.LED Fuse DiagnosticsBlown fuse LED indication for each output circuit provides a clear indication of faulty circuits and eases troubleshooting issues remotely.Cover/ Label RecessesProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.Ground Block IncludedIncludes a 12-position ground return block with multi-level low amp terminal screws for improved mounting.Ground Block SeparatesThe ground block section optionally separates from the fuse block section, affording increased deployment options for challenging installations.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 100a Fuse Type: ATO/ATC/ATF Type: Fuse Blocks Box Dimensions: 4"H x 5"W x 7"L WT: 0.7 lbs UPC: 850035199718 Quick Guide (pdf)

Read more less

MIDI-Fuse 100A/32V (Package of 5)Victron Energy's MIDI fuses are essentially a smaller version of the MEGA fuses and are known to have low voltage drop and cold resistance. This particular pack of Victron MIDI fuses contains five 100-amp fuses.Specifications: Max Current Rating: 100 amps Max Voltage Rating: 32 volts Approximate Voltage Drop: 60 mV Cold Resistance: 0.45 mΩ Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Amperage: 100a Fuse Type: MIDI/AMI Type: Fuses Box Dimensions: 0"H x 4"W x 7"L WT: 0.05 lbs UPC: 8719076036500 Quick Guide (pdf)Brochure (pdf)

Read more less

Fuse Trip C20 - 250AStrip Fuse C20 - 250 amp Specifications: Amperage: 250a Fuse Type: ANL Type: Fuses Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 8717372228797 Quick Guide (pdf)

Read more less

ATO Style Mixed Fuse KitTin Plated Zinc Alloy/Injection Molded Nylon.ATO Style Mixed Fuse Kit includes five each of 3A, 5A, 7.5A, 10A, 15A, and 20A fuses. Constructed of injection molded nylon with tin plated connector blades for superior conductivity and improved corrosion resistance. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: Assorted Fuse Type: ATO/ATC Type: Fuses Box Dimensions: 1"H x 2"W x 5"L WT: 0.1 lbs UPC: 035514445696

Read more less

Terminal FuseColor: RedAmperage: 50A Interrupt Rating satisfies ABYC requirements for DC Main circuit protection on large battery banks Ignition protected-safe for installation aboard gasoline powered boats Clear window-visual indication of blown condition Must be used with terminal fuse block WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.05 lbs UPC: 632085051778

Read more less

RT Fuse Block - 4 Circuit with CoverThe Egis RT Fuse Block is designed for optimal organization and protection of your electrical circuits. This 4-circuit fuse block comes with a durable cover, ensuring safety and reliability for your electrical systems. Ideal for automotive, marine, and various other applications, it simplifies the management of your fuses, making maintenance easier than ever. Each circuit is marked, allowing for quick identification and troubleshooting. The robust construction of the EGIS MOBILE RT Fuse Block ensures it can withstand the rigors of daily use while providing secure connections. Whether you're an enthusiast or a professional, this fuse block is an essential addition to your toolkit, offering peace of mind and superior performance.Features: 4 Circuits: Provides ample space for managing multiple electrical connections.:  Durable Cover: Offers protection against dust and accidental contact. Clear Markings: Facilitates easy identification and maintenance of circuits. Robust Construction: Built to withstand rigorous use in various environments. Specifications: Circuit Positions: 4 Cover Included This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

ATM Mini Blade Style Mixed Fuse KitTin Plated Zinc Alloy/Injection Molded Nylon.ATM Mini Blade Style Mixed Fuse Kit includes five each of 3A, 5A, 7.5A, 10A, 15A, and 20A fuses. Constructed of injection molded nylon with tin plated connector blades for superior conductivity and improved corrosion resistance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: Assorted Fuse Type: ATM Mini Type: Fuses Box Dimensions: 2"H x 2"W x 5"L WT: 0.05 lbs UPC: 035514445672

Read more less

ATM Mini Style Inline LED Fuse Holder - Up to 30AThis Sea-Dog LED inline mini fuse holder is meant for ATM mini-style fuses.Features: LED indicator that lights up when the fuse is blown Designed to accept ATM mini automotive-style spade terminal fuses For use with Sea-Dog ATM Mini Style Fuses 445002-445030 (sold separately). 12 gauge, 6” AWM wire lead Constructed of injection-molded PVC. IP67 waterproof rating Specifications: Max Amps: 30 Fuse Holder Length: 1-9/16 in. Fuse Holder Width: 15/16 in. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATM Mini Type: Fuse Holders Box Dimensions: 2"H x 2"W x 5"L WT: 0.1 lbs UPC: 035514446495

Read more less

5139 40AMP MAXI FuseFeatures: Economical Tin-plated connector blades for corrosion resistance Visible indication of blown condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Fuse Type: MAXI Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.02 lbs UPC: 632085051396

Read more less

V8 Series 30 AMP Mini-ANL Fuse - 2 PackT-Spec high-current fuse protects your equipment and you in the event of an electrical short circuit.  Each of these heavy-duty fuses features a little window through which you can visually check the fuse's status.Features: Nickel plated Status window *Sold as a 2 PackWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Fuse Type: ANL Mini Type: Fuses Box Dimensions: 4"H x 4"W x 7"L WT: 0.5 lbs UPC: 086429272204

Read more less

V8 Series 100 AMP ANL Fuse - 2 PackT-Spec high-current fuse protects your equipment and you in the event of an electrical short circuit.  Each of these heavy-duty fuses features a little window through which you can visually check the fuse's status.Features: Nickel plated Status window *Sold as a 2 PackWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 100a Fuse Type: ANL Type: Fuses Box Dimensions: 1"H x 5"W x 7"L WT: 0.1 lbs UPC: 086429272129

Read more less

MRBF Terminal Fuse - 90AFeatures: Transparent Easy Visual of Fuse Status Ignition Protected SAE/J1171-ISO8846 High Interrupt Rating Satisfies ABYC Requirements For DC Main Circuit Protection On Large Battery Banks Color Coded For Easy ID Of Amperage Rating This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 90 Fuse Type: Terminal Type: Fuses Box Dimensions: 2"H x 2"W x 5"L WT: 0.1 lbs UPC: 850053879609 Brochure (pdf)

Read more less

MRBF Terminal Fuse - 80 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 80 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 80a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879593

Read more less

MRBF Terminal Fuse - 60 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 60 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 60a Fuse Type: Terminal Type: Fuses Box Dimensions: 2"H x 2"W x 5"L WT: 0.09 lbs UPC: 850053879579

Read more less

Fuse MIDI/AMI 150A - PairFeatures: Compact fuse with 150A amperage Tin-plated copped for corrosion resistance Clear cover offers visible indication of blown fuses Color-coded for easy amperage identification Ignition protected to SAE J1171 when used with Blue Sea Systems SafetyHub family of products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 150a Fuse Type: MIDI/AMI Type: Fuses Box Dimensions: 1"H x 2"W x 3"L WT: 0.05 lbs UPC: 632085052584 Brochure (pdf)

Read more less

12 Position Fuse Block ATC with Yellow SlideThis 6 and 12-position marine fuse block offers a clean, organized solution for managing low-voltage electrical circuits in boats, RVs, and off-grid systems. Designed to centralize and protect up to 12 independent circuits, it provides dependable circuit separation for complex power layouts.Rated for 48V DC systems and up to 100A of input current, the block uses M5 threaded studs for the main input and M4 threaded studs for outputs, supporting up to 25A per circuit. It’s compatible with 88 Series breakers.Built with stainless steel hardware, nickel-plated copper conductors, and a tough polycarbonate body, this marine fuse block is made to withstand demanding environments. Mounting is straightforward with 0.1750” holes, spaced at 3.709” H x 2.331” W for the 6-position model and 5.285” H x 2.325” W for the 12-position version.Whether you’re building a new power system or upgrading an existing one, this fuse block delivers professional-grade performance and a tidy, serviceable layout.Specifications: Max Voltage: 48V DC Input Current: 100A Breaker Type: 88 Series/BW 38 Series Input Terminal Rating: M5 Threaded Studs (100A max) Output Terminal Rating: M4 Threaded Studs (25A max) Material: Stainless Steel/Nickel-plated Copper/Polycarbonate Installation: M5 main connecting studs Mounting Holes: 0.1750” Distance Between Mounting Holes: 6 Position: 3.709” H / 2.331” W 12 Position: 5.285” H / 2.325” W Specifications: Amperage: 200 Type: Fuse Blocks Box Dimensions: 2"H x 6"W x 10"L WT: 0.65 lbs UPC: 810196332331

Read more less

6 Position Fuse Block ATC with Yellow SlideThis 6 and 12-position marine fuse block offers a clean, organized solution for managing low-voltage electrical circuits in boats, RVs, and off-grid systems. Designed to centralize and protect up to 12 independent circuits, it provides dependable circuit separation for complex power layouts.Rated for 48V DC systems and up to 100A of input current, the block uses M5 threaded studs for the main input and M4 threaded studs for outputs, supporting up to 25A per circuit. It’s compatible with 88 Series breakers.Built with stainless steel hardware, nickel-plated copper conductors, and a tough polycarbonate body, this marine fuse block is made to withstand demanding environments. Mounting is straightforward with 0.1750” holes, spaced at 3.709” H x 2.331” W for the 6-position model and 5.285” H x 2.325” W for the 12-position version.Whether you’re building a new power system or upgrading an existing one, this fuse block delivers professional-grade performance and a tidy, serviceable layout.Specifications: Max Voltage: 48V DC Input Current: 100A Breaker Type: 88 Series/BW 38 Series Input Terminal Rating: M5 Threaded Studs (100A max) Output Terminal Rating: M4 Threaded Studs (25A max) Material: Stainless Steel/Nickel-plated Copper/Polycarbonate Installation: M5 main connecting studs Mounting Holes: 0.1750” Distance Between Mounting Holes: 6 Position: 3.709” H / 2.331” W 12 Position: 5.285” H / 2.325” W Specifications: Amperage: 100 Type: Fuse Blocks Box Dimensions: 2"H x 6"W x 8"L WT: 0.5 lbs UPC: 810196332324

Read more less

Terminal Block - 30 Amp - 6 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine-grade materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Specifications: Amperage: 30 Fuse Type: Terminal Box Dimensions: 1"H x 2"W x 6"L WT: 0.15 lbs UPC: 850053879708 Brochure (pdf)

Read more less

ST Blade Compact Fuse Blocks - 4 Circuits w/CoverProvides surface mount circuit protection for ATO®/ATC® Fuses in a compact footprint. The single side design allows wire entry from one side to maximize space. Compact common source fuse block Accepts ATO® and ATC® fast acting blade fuses Single side entry wiring Ignition Protected-meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment Insulating cover meets ABYC/USCG insulation requirements Tin-plated copper buses and fuse clips Accepts ring or snap fork type terminals Small format standard and custom labels available Specifications Circuits:4 Maximum Amperage: 100A per block / 30A per circuit Maximum Voltage:32V DC Mounting: #8 Screw (M4) Screw Terminal Torque:#8-32 Screws with captive star lock washer in-lb (0 Nm) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Blocks Box Dimensions: 2"H x 3"W x 8"L WT: 0.5 lbs UPC: 632085050450

Read more less

MRBF Terminal Fuse - 100 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 100 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 100a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 1"W x 6"L WT: 0.1 lbs UPC: 850053879616

Read more less

MRBF Dual Output Terminal Block - 30-300 AmpFeatures: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. Ignition Protected When Used With Egis Mobile Electric MRBF Fuses safe for installation in closed compartments with potential explosive gases. Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation  58 Vdc Rating: easily supports 12 to 48V nominal applications. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30-300A Stud Size: M8 (5/16") Mounting Hole Size: M10 (3/8") Interrupt Rating @ 48 Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 30-300 Fuse Type: Terminal Type: Fuse Blocks Box Dimensions: 3"H x 3"W x 5"L WT: 0.3 lbs UPC: 850053879531 Brochure (pdf)

Read more less

MEGA Fuse 200A/80V (Package of 5 Pieces)Victron Energy supplies a range of fuse holders and fuses to suit a wide range of installations, and the MEGA fuses are frequently used in Victron Energy DC distribution systems. This particular pack of ceramic Victron MEGA fuses contains FIVE 200 AMP fuses.Features:For 80V productsSpecifications: Max Current Rating: 200 AMP Max Voltage Rating: 80V Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Amperage: 200a Type: Fuses Box Dimensions: 0"H x 6"W x 6"L WT: 0.25 lbs UPC: 8719076061700

Read more less

ST-Blade Battery Terminal Mount Fuse Block KitFeatures: Easy to install 4 ATO/ATC fused circuits Mounts on the battery terminal stud Screw terminals for securing wires Eight nylon ring terminals included Insulating cover included Kit Includes: 1 - 5023 ST-Blade Battery Terminal Mount Fuse Block Battery Terminal Mount BusBars WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Blocks Box Dimensions: 2"H x 8"W x 8"L WT: 0.6 lbs UPC: 632085050245

Read more less

Terminal FuseColor: LimeAmperage: 80A Interrupt Rating satisfies ABYC requirements for DC Main circuit protection on large battery banks Ignition protected-safe for installation aboard gasoline powered boats Clear window-visual indication of blown condition Must be used with terminal fuse block WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 80a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 3"W x 4"L WT: 0.05 lbs UPC: 632085051815

Read more less

ST-Blade Split Bus Fuse BlockFeatures: Provides two isolated groups of six ATO/ATC circuits For use with either two isolated batteries or with a single battery providing a mix of 24 hour and switched circuits Screw terminals for securing wires accept ring terminals One-piece stainless flange nuts ensure safe and secure connections Clear insulating cover with label recesses and storage for two fuses, satisfies ABYC/USCG insulation requirements Easy to open, push button latch for easy access to fuses Tin-plated copper buses and fuse clips Fuses sold separately Specifications: Circuits: 12 Maximum Amperage: 100A per block, 30A per circuit Maximum Voltage: 32V DC Mounting: #8 Screw (M4) Negative Bus: #10-32 Stud Screw Terminal Type: #8-32 Screws with captive star lock washer WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Blocks Box Dimensions: 2"H x 6"W x 10"L WT: 0.91 lbs UPC: 632085050320

Read more less

5064ATO/ATC In-Line Fuse Holder Supplied with 12 AWG pigtails 30A Maximum fuse amperage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Holders Box Dimensions: 1"H x 2"W x 5"L WT: 0.05 lbs UPC: 632085050641

Read more less

5236ATO/ATC Fuse2A Fast-acting type fuse ideal for electronic devices Standard circuit protection device for automobiles and trucks Tin-plated connector blades for corrosion resistance Visible indication of blown condition Sold in packages of 2 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 2a Fuse Type: ATO/ATC Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.02 lbs UPC: 632085052362

Read more less

Terminal FuseColor: GoldAmperage: 60A Interrupt Rating satisfies ABYC requirements for DC Main circuit protection on large battery banks Ignition protected-safe for installation aboard gasoline powered boats Clear window-visual indication of blown condition Must be used with terminal fuse block WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 60a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 4"L WT: 0.05 lbs UPC: 632085051785

Read more less

MEGA or AMG Fuse Safety Block Ignition protected for installation aboard gasoline or diesel powered boats Sealed cover protects fuses from the harsh marine environment Insulating cover satisfies ABYC/USCG insulation requirements Cover breakouts allow wire access in any direction 300A maximum with 2/0 cable Accepts Blue Sea Systems Square Format standard or custom label Fuses sold separatelyWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: MEGA/AMG Type: Fuse Blocks Box Dimensions: 2"H x 4"W x 8"L WT: 0.49 lbs UPC: 632085077211 Brochure (pdf)

Read more less

MRBF Terminal Fuse - 200 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 200 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 200a Fuse Type: Terminal Type: Fuses Box Dimensions: 2"H x 2"W x 5"L WT: 0.09 lbs UPC: 850053879654

Read more less

Replacement Shunt for BMV Monitors - *PCB is NOT Included*Replacement 500A/50MV shunt for BMV Monitors*BMV PCB is NOT included and must be purchased separately*Warranty InfoPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

5101 MEGA®/AMG® Fuse - 100AMPFeatures: Most economical fuse for 100-300 Ampere circuit protection For use with Blue Sea Systems' MEGA®/AMG® Fuse Block WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 100a Fuse Type: MEGA/AMG Type: Fuses Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085051013

Read more less

Communication Cable SG2320 (N2K) & SG240 (RB-C) M12 - 12"Com Cable connecting to an RV-C CANbus Network via an M12 DeviceNet Connector.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

325A/80V CNN Fuse for Lynx ShuntVictron's 325A/80V fuse is designed to fit the Lynx Shunt VE. CanSpecifications: Rated Amperage: 325A Rated Voltage: 80V Terminal Size: 10mm Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Amperage: 325a Type: Fuses Box Dimensions: 1"H x 4"W x 6"L WT: 0.1 lbs UPC: 8719076021940

Read more less

RT Fuse Block 12 Position with Ground & LED IndicationThis 12-position fuse block has a modular design that can produce seven (7) unique configurations from Egis 8028 & 8030 and reduce part numbers to stock for all build requirements. Also, this fuse block has a ground and LED indication.Applications: Blown fuse LEDs speed up the correction of system faults and improve the ability to remotely diagnose customer issues. Harsh environment design with stainless steel self-locking hardware and optional weather-proof labels in standard or customized options. Features: Bullet-proof construction - designed with high-temperature materials and stainless steel self-locking hardware allows mounting anywhere on the vehicle Protects branch circuits by accepting ATO style fuses ranging from 1 through 40 Amps Supports SAE circuit protection standards for thermal/short circuit events Specifications: Maximum Current (Entire Block) Amps: 10 Maximum Current (Per Circuit) Amps: 30 Max Output Wire Size: #10 AWG Voltage Range VDC: 0-36 Number of Fuse Positions: 12 Compatible Fuse Types: ATO / ATC / ATF Focal Features:Spare Fuse LocationsTwo locations per 6 circuits for spare or test resistors to reduce siren volumes during evaluation.Stainless Steel Self-Locking Hardware100 % non-ferrous corrosion-resistant materials. All attachment screws and nuts are self-locking.LED Fuse DiagnosticsBlown fuse LED indication for each output circuit provides a clear indication of faulty circuits and eases troubleshooting issues remotely.Cover/ Label RecessesProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.Ground Block IncludedIncludes a 12-position ground return block with multi-level low amp terminal screws for improved mounting.Ground Block SeparatesThe ground block section optionally separates from the fuse block section, affording increased deployment options for challenging installations.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 100a Fuse Type: ATO/ATC/ATF Type: Fuse Blocks Box Dimensions: 3"H x 4"W x 8"L WT: 1 lbs UPC: 850035199725 Quick Guide (pdf)

Read more less
