Fluid Level SensorTransmits the tank level from a suitable tank level sender unit on the the NMEA 2000 network. Replaces EP-65 Reports Tank Fluid Level: 0-100% Pre-configured for Fuel Tank Instance 0 Pre-calibrated to the 33-240j U.S. marine standard tank level sender Can re-calibrated via compatible Navico MFDs to other standard levels Can be reconfigured* to output the following level types: Water, Gray Water, Live Well, Oil, Black Water.Cable Length 10 feet and comes with a Micro-C T-Connector. Specifications: Connection Gender: Male Data Interface: NMEA 2000 Cable Length (Meters): 3m Box Dimensions: 3"H x 4"W x 10"L WT: 0.59 lbs UPC: 9420024129869

Read more less

GA200 GPS Sensor for AIS700The GA200 is an external antenna, suitable for improving the reception of the internal GNSS (GPS / GLONASS) receivers of compatible MFDs, AIS devices, and VHF radios. The GNSS antenna is supplied with a fitted 10 m (33 ft.) cable. The length of the antenna cable can be extended if required. The antenna cable length can be extended by up to 10 m (33 ft.), giving a total maximum cable length of 20 m (66 ft.)

Read more less

NMEA 2000® Backbone/Drop CableExtend your NMEA 2000® backbone with Garmin's 13' (4M) backbone/drop cable.Compatible Devices: AIS™ 300/600 Blackbox Transceiver GBT™ 10 GCL™ 20 Low-light Imaging Camera GDL™ 40 GET™ 10 GFL™ 10 GFS™ 10 GHP™ 12 Autopilot System GHP™ 20 Marine Autopilot System for Steer-by-Wire, Viking® and Yamaha® Helm Master™ GHP™ 20 Marine Autopilot System with SmartPump GMI™ 10/20 Marine Instrument GPS 19x NMEA 2000® GPSMAP® Series VHF 200/300 Marine Radio VHF 300 AIS WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 4m Box Dimensions: 1"H x 5"W x 6"L WT: 0.4 lbs UPC: 753759978198

Read more less

PRO NMEA 0183 MultiplexerEight OPTO-isolated inputs and six ISO-Drive™isolated outputs. Offering device protection and excellent flexibility, all in one product.Introducing the Actisense® PRO-MUX-2, the intelligent, type-approved PRO range multiplexer.The PRO-MUX-2 is rugged, with a stainless steel housing, and provides isolation on all inputs and outputs. With eight NMEA 0183 inputs, six NMEA 0183 outputs, a bi-directional serial port and an Ethernet port, the PRO-MUX-2 is a perfect solution for larger leisure vessels, commercial shipping and is a great addition for systems that require type-approved devices.The PRO-MUX-2 is designed to suit the majority of NMEA 0183 systems, from leisure through to class vessels.Features: 8 OPTO-isolated NMEA 0183 inputs 6 ISO-Drive NMEA 0183 outputs Bi-directional isolated serial port (can be used for additional NMEA 0183 input/ output) 0183 streaming via Ethernet Alarm output (N/O and N/C contacts) Designed for 12- and 24-Volt supply Isolation to battery supply Configurable input and output baud rates for rate conversion Data combining from any input to any output 2 independent Autoswitch virtual inputs with priority Advanced sentence-based filtering / routing Diagnostic LEDs on all inputs and outputs Alarm, mode and Bi-colour Status LED’s 2-part pluggable connector system supports both screw and screwless terminals DIN rail or Panel mountable Advanced statistics are available via a Web Browser Quick and easy to install Configuration using standard web browser, no PC operating system compatibility issues Advanced features solve NMEA 0183 data routing problems Fully isolated with ISO-Drive technology for peace of mind Easy firmware updates makes the device future-proof Technical Specifications:Power Supply Input Supply Voltage - 9 to 35 V DC Input Supply Current - 220mA max @ 12V DC (all outputs @ full drive into 100 ohm loads) Input Protection - Continuous reverse polarity, transient overvoltage and ESD protection Power Indicator - LED, Blue – indicates unit is functioning correctly Input Supply Connector - Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 8 isolated NMEA 0183 Listeners Number of Talker / Output Ports - 6 isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 4800 to 38400 bps Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm Talker Output Current Drive - 20 mA maximum per output Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes at data rate) Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Listener Input Protection - Current limited, overdrive protection to 40 VDC and ESD protection Listener Data Indicator - LED, Green (Flashes to indicate valid input) Connectors - Pluggable 2/3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Serial Port Compatibility - RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 4800 to 115200 bps Output Voltage Drive - >= 2.1V (differential) into 100 ohm Output Current Drive - 20 mA max. Output Protection - Short circuit and ESD Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Input Protection - Current limited, overdrive protection to 40 VDC and ESD protection Data Indicators - LED’s: Green = Receive, Orange = Transmit Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Ethernet Port Host Interface - 10/100BaseT, automatic polarity detection Supported Protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms Indicators - Green = Link/Activity, Yellow = 100 Mbps Connector - RJ45 Isolation NMEA 0183 Listener - OPTO-Isolated, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDrive™, Hi-Pot tested to 1000V Serial Port - Uses IsoDrive™, Hi-Pot tested to 1000V Alarm Relay - Hi-Pot tested to 1000V Ethernet Port - 2kV for 60s Mode Inputs Input Voltage Range - 0 to 35V DC Protection - Transient overvoltage and ESD protection Connectors - Pluggable 2-way screw terminals, 5.08mm pitch (12 to 30 AWG) Alarm Output Contacts - Common, Normally Open and Normally Closed Alarm Indicator - LED, Red indicates a valid alarm condition Contact Ratings - 35VAC / 50VDC Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Mechanical Housing Material - 316 Stainless Steel Dimensions - 210mm (W) x 128mm (H) x 27mm (D) Weight - 540g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications Compass Safe Distance - 175mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 10"L WT: 1.5 lbs UPC: 5060998710584 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Rear Panel Mount NMEA2000 Wired Micro 5-Pin - MalePanel mount wired connectors available from Actisense allow NMEA 2000 installations through watertight bulkheads (or panels) to be achieved.Waterproof seals ensure the integrity of the NMEA 2000 connection and bulkhead/panel.The female panel mount wired connector can easily replace any of the existing ‘drop’ glands on the Actisense QNB-1 to create a quick pluggable NMEA 2000 connection option.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications:Electrical Rated Current - 4A Rated Voltage - 60VDC Mechanical Contacts - Brass, gold-plated Contact Carrier - Nylon & GF Contact Polarization - Standard M12-"A"-Polarization Mating Thread - M12 Housing - Brass, nickel-plated Mounting Thread - PG9 Mounting Nut - Brass, nickel plated - PG9 Mounting Hole Diameter - 15.3mm Wires - 18 AWG (stripped and tinned) Wire Jacket - PVC Weight - 20g Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -25°C to +90°C Connector Specification - Meets IEC61076-2-101 This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male Data Interface: NMEA 2000 Box Dimensions: 1"H x 4"W x 6"L WT: 0.05 lbs UPC: 5060998710164 Owner's Manual (pdf)Brochure (pdf)

Read more less

PRO NMEA Buffer - 1 OPTO Input, 6 ISO-Drive Outputs, Serial Port, Pluggable Screw TerminalsSafely connect one Talker to six Listeners with full isolation.The Type-approved NMEA Buffer PRO-NBF-1 Buffer isolates and buffers NMEA 0183 data, with the power to drive multiple devices.Able to distribute up to six identical, amplified streams of data from one source, the NMEA signals are buffered to ensure that each Listener receives the data at the required voltage levels, providing consistent data quality.Isolation of the input and outputs ensures the protection of the source Talker device and Listener devices.The NMEA Buffer has ISO-Drive™ technology on the outputs and OPTO-isolation on the input, which enables you to connect the NMEA 0183 Buffer with complete peace of mind.The stainless steel housing makes the device rugged, sturdy, and gives it increased durability. The metal case also acts as an RF Shield, making the device an ideal addition to commercial installations.To make installation quick and simple, the PRO-NBF-1 features 2-part pluggable connectors that allow use of screw terminals*, and a professional DIN Rail mounting system (DIN Rail not included). The device can also be mounted directly to the bulkhead.The optional strain relief brackets can be provided to ensure reliable professional cable management.Helpful LEDs indicate power, input, and output operation.Features: One Opto-Isolated Input Six ISO-Drive™ outputs Outputs automatically track the input baud rate RS-232, RS-422 and RS-485 Listener compatible ISO-Drive separates the Listener from the Talker to protect both the PRO-NBF-1 and each connected device Wide compatibility means simplified installation Simple installation saves time and money and provides peace of mind Type Approved (RINA) Technical Specifications:Power Supply Input Supply Voltage - 9 to 35V DC Input Supply Current - 150mA max @ 12V DC (all outputs @ full drive into 100Ω loads) Input Protection - Continuous reverse polarity and ESD protection Power Indicator - LED, Blue – Indicates unit is functioning correctly Input Supply Connector - Pluggable 2-way screw terminal, 5.08mm pitch NMEA 0183 Port – Listener & Talkers Number of Listener / Input Ports - One isolated NMEA 0183 Listener Number of Talker / Output Ports - Six isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS-485 Listener compatible Speed/baud rate - 4800 to 115200 bps Talker Output Voltage drive - >= 2.2V (differential) into 100Ω Talker Output Current drive - 20mA max. Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes at data rate) Listener Input Voltage Tolerance - -15V to +15V continuous, -35V to +35V short term (<1 second) Listener Input Protection - Current limited, overdrive protection to 40V DC, and ESD protection Listener Data Indicator - LED, green (Flashes to indicate valid input) Connectors - Pluggable 2/3-way screw terminals, 5.08mm pitch Isolation NMEA 0183 Listener - OPTO-Isolated, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V Mechanical Housing Material - 316 Stainless Steel Dimensions - 139mm (L) x 128mm (W) x 27mm (H) Weight - 335g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - EN 60945:2002 (Fourth Edition – 2002), DNVGL-CG-0339:2019 Compass safe distance - 600mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Maximum Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 10"L WT: 1 lbs UPC: 5060998710546 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

A2K-TDC-3M NMEA2000 Micro Cable Assembly - 3MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  228g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 3m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 1"H x 7"W x 7"L WT: 0.5 lbs UPC: 5060998710249 Owner's Manual (pdf)Brochure (pdf)

Read more less

PRO NMEA 0183 Multiplexer - 5 Inputs & 2 ISO-Drive Outputs, Ethernet & Serial ConnectionsThe PRO-NDC-1E is more than just an NMEA 0183 Multiplexer…Rugged, Robust, type-approved multiplexer with powerful, advanced features enables baud rate adjustments, auto-switching, and sentence-level filtering.Features: Auto-switching between inputs to allow for a primary, secondary, and tertiary priority input. Configurable baud rates to allow 38400 and 4800 baud devices to operate through the same multiplexer. Sentence filtering to block unwanted sentences from specific outputs helps to limit bandwidth consumption. Easy to configure using the web-based UI, no need to manually enter and edit strings of text. RINA type-approved device means the multiplexer is fit for leisure, commercial, and class/type installations. Multiple LEDs allow for ‘quick glance’ diagnostics to ensure everything is operating correctly. NMEA 0183 data streaming over Ethernet enables connectivity to existing Ethernet devices and systems. 5 OPTO-Isolated NMEA 0183 inputs and 2 ISO-Drive NMEA 0183 outputs provide protection for all connected instruments. Dedicated bi-directional Serial port (fully isolated utilising ISO-Drive technology) A serial port can be used as an additional input/output Ethernet port supports direct and network connections NMEA 0183 streaming via Ethernet Configurable input and output baud rates Allows Data combining and rate conversion 2 independent Autoswitch virtual inputs with priority Isolation from battery supply Diagnostic LED’s Optional DIN rail mount Type Approved Quick and easy to install Configuration using a standard web browser, no PC operating system compatibility issues Advanced features solve NMEA 0183 data routing problems Fully isolated with ISO-Drive technology for peace of mind Easy firmware updates make the device future-proof Technical Specifications:Power Supply Input supply voltage - 9 to 35 V DC     Input supply current - 150mA max @ 12V DC (all outputs @ full drive into 100 ohm loads)     Input protection - Continuous reverse polarity, transient overvoltage, and ESD protection     Power indicator - LED, Blue – indicates unit is functioning correctly     Input Supply connector - Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 5 isolated NMEA 0183 Listeners     Number of Talker / Output Ports - 2 isolated NMEA 0183 Talkers     Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS-485 Listener compatible     Speed/baud rate - 4800 to 38400 bps     Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm     Talker Output Current Drive - 20 mA maximum per output     Talker Output Protection - Short circuit and ESD     Talker Data Indicator - LED, Orange (Flashes with data rate)     Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second)     Listener Input Protection - Current limited, overdrive protection to 40 VDC, and ESD protection     Listener Data Indicator - LED, Green (Flashes with data rate)     Connectors - Pluggable 2/3 way screw terminals, 5.08mm pitch (12 to 30 AWG) Serial Port Compatibility - RS422 & RS232 compatible. RS-485 Listener compatible     Speed/baud rate - 115200 bps     Output voltage drive - >= 2.1V (differential) into 100 ohms     Output current drive - 20 mA max     Output protection - Short circuit and ESD     Input voltage tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second)     Input protection - Current limited, overdrive protection to 40 VDC, and ESD protection     Data Indicators - LED’s: Green = Receive, Orange = Transmit     Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Ethernet Port Host interface - 10/100BaseT, automatic polarity detection     Supported protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms     Connector - RJ45     Indicators - Green – Link, Yellow – 100 Mbps Isolation NMEA 0183 Listener - Uses IsoDriveTM, Hi-Pot tested to 1000V     NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V     Serial Port - Uses IsoDriveTM, Hi-Pot tested to 1000V     Ethernet Port - 2kv for 60s Mechanical Housing Material - 316 Stainless Steel     Dimensions - 139mm (W) x 98mm (H) x 26mm (D)     Weight - 360g     Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - IEC 60945:2002-08, DNVGL-CG-0339:2019 & IACS UR E10 Rev7     Compass Safe Distance - 300mm     Type Approval Certificate - RINA     Operating Temperature - -25 to +70°C     Storage Temperature - -40 to +85°C     Relative Humidity (RH) - 95% @ 55°C     Environmental Protection - IP40     Guarantee - 3 years (5 Years if registered) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 10"L WT: 1 lbs UPC: 5060998710577 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

A2K-TDC-2M NMEA2000 Micro Cable Assembly - 2MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold-plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  166g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 2m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 1"H x 5"W x 6"L WT: 0.35 lbs UPC: 5060998710232 Owner's Manual (pdf)Brochure (pdf)

Read more less

A2K-TDC-1M NMEA2000 Micro Cable Assembly - 1MAvailable in various lengths, the cable assemblies can be used as either drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold-plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  105g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 1m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 1"H x 5"W x 5"L WT: 0.2 lbs UPC: 5060998710225 Owner's Manual (pdf)Brochure (pdf)

Read more less

0183 to N2K Gateway with PC Interface, USB ConnectionIntelligent Gateway technology enables PC interfacing and NMEA data conversion…The NGX-1 is an intelligent multi-function gateway, combining the power of our two previous generation products (NGT-1 and NGW-1) into one, cost effective, flexible product.Configure the NGX-1 to operate as an NMEA 2000 <–> PC interface, or as a bi-directional NMEA 0183 <–> NMEA 2000 conversion gateway.Features: View all NMEA 2000 network data on Actisense NMEA Reader. The device supports every available PGN in the NMEA 2000 standard. View converted NMEA 0183 data on Actisense NMEA Reader. The device sports the largest conversion library of any gateway. Easily interface with a wide range of PC applications via the NGX-1, such as TimeZero (NMEA 2000) and OpenCPN (NMEA 0183). Configure the Actisense EMU-1, NGW-1 and NGX-1 via Actisense Toolkit using an NGX-1. Connect legacy NMEA 0183 instruments together with new NMEA 2000 networks, greatly reducing upgrade costs. Vital NMEA 2000 diagnostic tool Fully isolated to prevent dangerous ground loops Up to 230,400 baud data transfer rate Advanced configuration using Actisense Toolkit allows Tx / Rx lists and Tx rates to be set Supports Fast Heading at 10Hz Multiple diagnostic LEDs Allows all major PC Chartplotter applications to interface with the NMEA 2000 bus Provides a rule-enforcing firewall between the PC and the NMEA 2000 bus Powerful diagnosis of the NMEA 2000 network using the FREE NMEA Reader software provided Configure and flash-update Actisense products on the bus Upgrade NMEA 0183 equipment to NMEA 2000 Allow NMEA 0183 devices to receive vital NMEA 2000 data Use the NMEA 2000 bus to multiplex several NMEA 0183 signals together Reliable, renowned bi-directional conversion engine Supports a wide range of conversions including AIS Easily configurable using Actisense Toolkit Technical SpecificationsPower Supply Supply Voltage (NMEA 2000 Port) - 9 to 30V DC Supply Current (NMEA 2000 Port) - 62mA @ 9V DC Load Equivalent Number (LEN) - 2 NMEA 2000 Port Speed / Baud Rate - 250kbps Connectivity - M12 Male (A coded) USB Port Compatibility - USB 1.1, 2.0 and 3.0 Speed / Baud Rate - 4800 to 230400 Baud Connectivity - Male type A plug moulded onto cable Cable Length - 1.8m Isolation NMEA 2000 Port to ISO Port - Uses IsoDriveTM, Hi-Pot tested to 1000V NMEA 2000 Port to USB Port - Galvanic Isolation, Hi-Pot tested to 1000V Mechanical Housing Material Body - Flame retardant Polycarbonate Housing Material End Caps - Flame retardant PBT Weight - 113g Approvals and Certifications NMEA 2000 - NMEA 2000 Certified NMEA 0183 - Meets IEC 61162-1 & 61162-2 Requirements RoHS and REACH - Compliant Module Certification - KCC / BQB / IC / Wi-Fi / NCC / MIC / FCC DSS / FCC DTS / SRRC / CE, EN 60945:2002 Edition 4 (section 9.3), EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4 EMC - EN 300 328 V2.2.2 Radiated Spurious Emissions, FCC Part 15b, ICES-003 Iss 7 Environmental Protection    IP67 Operating Temperature    -25°C to +70°C Storage Temperature    -30°C to +70°C Recommended Humidity    0 to 93% RH @ 40°C Guarantee    3 years, extended to 5 years upon registration This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 0183 Box Dimensions: 2"H x 6"W x 6"L WT: 0.5 lbs UPC: 5060998710560 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Protective Screw Cover f/N2K Male Micro Connectors - 10-Pack (Female Threaded)Screw-cap covers for NMEA 2000 male micro connectors.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Female Data Interface: NMEA 2000 Box Dimensions: 1"H x 1"W x 5"L WT: 0.03 lbs UPC: 5060998710805

Read more less

IF-NMEA2K2The IF-NMEA2K2 is an interface to convert data from NMEA0183 format to NMEA2000 / CAN bus format and vice versa. In addition to the normal conversion mode, the High Speed mode to convert sensor data for Autopilot as well as an AIS mode dedicated to AIS data are available in one compact unit. With these three modes, you can optimize the conversion speed depending on the situational requirements. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 2000 Box Dimensions: 1"H x 8"W x 11"L WT: 1 lbs UPC: 611679345332 Owner's Manual (pdf)

Read more less

NMEA 2000 Drop Cable - 2 MeterThis NMEA 2000 5-pin drop cable is built for seamless integration between your network backbone and connected marine electronics. Designed with durable, waterproof connectors, it ensures a secure and interference-free connection to displays, GPS units, sensors, and more. Built to NMEA 2000 standards, this drop line supports dependable communication across all major marine brands.Whether you’re expanding your system or replacing a worn connection, this marine network cable is an essential component for clean, efficient, and reliable wiring.Made from rugged materials, it resists saltwater corrosion, UV exposure, and mechanical wear, ensuring long-lasting performance in demanding marine environments. Specifications: Connection Gender: Female-Male Data Interface: NMEA 2000 Cable Length (Meters): 2m Box Dimensions: 1"H x 6"W x 10"L WT: 0.35 lbs UPC: 810196330276 Brochure (pdf)

Read more less

Termination Resistors are required on a NMEA 2000 network and are placed at each end of a network trunk cable. Like the double-ended cordsets, the termination resistors are waterproof and continue to function even while submerged in the bilge. Diagnostic versions indicate correct polarity at a glance to ensure power connections have been made properly Screw connector for positive connnection Termination resistors are used to terminate both ends of the trunk line Specifications: Connection Gender: Male Data Interface: NMEA 2000 NMEA 2000 Connectors: Terminators Box Dimensions: 1"H x 1"W x 2"L WT: 0.15 lbs UPC: 873804002361

Read more less

Maretron NM-CF Mini Male to Micro Female ReducerThe reducer is used to change from a Mini cable to Micro or Mid cable. For example, one end of the network might be terminated at the top of the mast but it may not be desireable to run a Mini trunk cable up the mast. In this case, you can switch over to Micro or Mid cable at the base of the mast using the reducer and continue up the mast with Micro or Mid cable.Corrosion resistant Nickel plated Brass Weatherproof to IP67 Reduces Mini Backbone to Micro/Mid Cable Specifications: Connection Gender: Male-Female Box Dimensions: 1"H x 3"W x 3"L WT: 0.2 lbs UPC: 873804002002

Read more less

T-ConnectorFor use with red NMEA network Specifications: Data Interface: NMEA 2000 NMEA 2000 Connectors: Tee Connectors Box Dimensions: 2"H x 3"W x 5"L WT: 0.1 lbs UPC: 042194529677

Read more less

NMEA 2000 in-line terminatorWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Data Interface: NMEA 2000 Box Dimensions: 1"H x 2"W x 2"L WT: 0.1 lbs UPC: 753759078430

Read more less

Solid-State Rate/Gyro Compass w/10m Cable & ConnectorMaretron's SSC300, implementing the second generation of Maretron's award-wining compass technology, is a solid state, rate gyro electronic compass that provides better than 0.7x heading accuracy through q45x of roll and pitch angle, and better than 1x roll and pitch accuracy in static conditions. Each SSC300 is factory calibrated for maximum accuracy. It delivers precise, reliable heading information ten times per second, plus vessel attitude including pitch and roll readings once per second. A micromachined 3-axis rate gyro is used, in conjunction with a 3-axis accelerometer, by advanced stabilization algorithms to provide accurate, stable readings during dynamically changing conditions such as hard turns or rough seas, making it an ideal heading sensor for autopilot or radar overlay applications.Maretron's SSC300 is certified to the NMEA 2000 network standard and compatible with the NMEA 0183 digital interface standard. It connects directly with any NMEA 2000 network and with the optional NMEA 0183 cable accessory, with NMEA 0183 listeners to share information with navigational software, chart plotters, autopilots, and dedicated instrument displays - including Maretron's N2KView vessel monitoring system, or Maretron's DSM150 /DSM250 color graphics displays.The SSC300 can be automatically calibrated for deviation. Its dynamic accuracy is improved with advanced digital filtering of the 3-axis magnetometer, 3-axis accelerometer and rate gyro.Features: Better than 0.7x heading accuracy in static conditions Better than 1.5x heading accuracy in dynamic conditions Better than 1x/second rate of turn in Better than 1x pitch/roll accuracy Three axis magnetometer, three axis rate gyro, and three axis accelerometer Outputs NMEA 0183 and NMEA 2000 data simultanously IP67 waterproof enclosure Applications: Navigation Autopilot Radar stabilization Satellite antenna stabilization Swing meter WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications: Cable Length (Meters): 10m Box Dimensions: 1"H x 1"W x 1"L WT: 2.9 lbs Owner's Manual (pdf)Brochure (pdf)

Read more less

Solid-State Rate/Gyro Compass without CablesMaretron's SSC300, implementing the second generation of Maretron's award-wining compass technology, is a solid state, rate gyro electronic compass that provides better than 0.7x heading accuracy through q45x of roll and pitch angle, and better than 1x roll and pitch accuracy in static conditions. Each SSC300 is factory calibrated for maximum accuracy. It delivers precise, reliable heading information ten times per second, plus vessel attitude including pitch and roll readings once per second. A micromachined 3-axis rate gyro is used, in conjunction with a 3-axis accelerometer, by advanced stabilization algorithms to provide accurate, stable readings during dynamically changing conditions such as hard turns or rough seas, making it an ideal heading sensor for autopilot or radar overlay applications.Maretron's SSC300 is certified to the NMEA 2000 network standard and compatible with the NMEA 0183 digital interface standard. It connects directly with any NMEA 2000 network and with the optional NMEA 0183 cable accessory, with NMEA 0183 listeners to share information with navigational software, chart plotters, autopilots, and dedicated instrument displays - including Maretron's N2KView vessel monitoring system, or Maretron's DSM150 /DSM250 color graphics displays.The SSC300 can be automatically calibrated for deviation. Its dynamic accuracy is improved with advanced digital filtering of the 3-axis magnetometer, 3-axis accelerometer and rate gyro.Features: Better than 0.7x heading accuracy in static conditions Better than 1.5x heading accuracy in dynamic conditions Better than 1x/second rate of turn in Better than 1x pitch/roll accuracy Three axis magnetometer, three axis rate gyro, and three axis accelerometer Outputs NMEA 0183 and NMEA 2000 data simultanously IP67 waterproof enclosure Applications: Navigation Autopilot Radar stabilization Satellite antenna stabilization Swing meter WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

SeaTalkng Terminators attach at each end of SeaTalk backbone. Two are required per system.

Read more less

Mini Field-Attachable ConnectorsField-attachable connections allow you to make field connections to bulk cable. The color-coded screw terminals match the individual wire colors found within the bulk cables for error-free field installationColor-coded screw terminators make for error-free field installation Rugged housing material designed to withstand harsh marine environments Specifications: Connection Gender: Female NMEA 2000 Connectors: Field Connectors Box Dimensions: 1"H x 1"W x 5"L WT: 0.13 lbs UPC: 873804002279

Read more less

Micro Cap - Used to Cover Female ConnectorMicro cap used to cover female connectors. Specifications: Connection Gender: Female Box Dimensions: 1"H x 1"W x 1"L WT: 0.1 lbs UPC: 873804001388

Read more less

Transom Mount Speed SensorTransom-mount paddle wheel 3.1 m (10ft) cable with Micro-C connector.Features Replaces EP-70 Outputs speed through water Transom-mount paddle wheel Ideal for slow, trolling speeds, where GPS is not as accurate Share paddle wheel speed to any networked display, unlike sonar based paddlewheel sensors Specifications: Connection Gender: Male Data Interface: NMEA 2000 Cable Length (Meters): 3.1m Box Dimensions: 3"H x 4"W x 10"L WT: 0.71 lbs UPC: 9420024129876

Read more less

Fuel Data ManagerMonitors Fuel Rate/Fuel Flow from NMEA 2000 engines, and accumulates Fuel Rate into Fuel Used. Outputs seasonal, trip and total fuel used.Features Replaces EP-85 Monitors Fuel Rate/Fuel Flow from NMEA 2000 engines, and accumulates Fuel Rate into Fuel Used Outputs: Seasonal/Trip/Total Fuel Used Will report accurate Vessel Fuel Remaining if MFD Fuel screen is maintained at every refuel One sensor will monitor up to 3 engines Additional Fuel Data Managers can be added for more engines Will monitor fuel rates from multiple engines transmitting through a single gateway Specifications: Connection Gender: Male Data Interface: NMEA 2000 Cable Length (Meters): 0.5m Box Dimensions: 3"H x 4"W x 10"L WT: 0.3 lbs UPC: 9420024129906

Read more less

A2K-TDC-4M NMEA2000 Micro Cable Assembly - 4MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  287g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 4m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 1"H x 5"W x 6"L WT: 0.65 lbs UPC: 5060998710256 Owner's Manual (pdf)Brochure (pdf)

Read more less

WS2-C06 NMEA 2000 Cable for Heading Sensor WeatherWith NMEA 2000 output only. End in a standard male 5-Pin NMEA 2000 connector 6M cable.6M/20'This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Data Interface: NMEA 2000 Cable Length (Meters): 6m Box Dimensions: 2"H x 9"W x 9"L WT: 0.8 lbs UPC: 801769002980

Read more less

SIM100 Switch Indicator ModuleMaretron's Switch Indicator Module monitors switch closure devices including, but not limited to, safety equipment (heat, smoke, carbon monoxide, explosive vapor detectors), security systems (motion, vibration, glass break, door and port hole magnetic switches), and vessel monitoring equipment (valve closed/open, high water bilge). The SIM100 continually monitors these switch closure devices and broadcasts information of the NMEA 2000 network about the switch state so the crew can be alerted to potential conditions or problems that warrant further investigation. Advanced features of the SIM100 include the ability to detect whether or not power has been disconnected frmo the monitored device or if the signal wires have been disconnected due to either corrosion, tampering, or for any other reason (if the monitored device is so equipped). With the SIM100, you can rest assured that ciritcal sensors are receiving power, signal wires are connected, and all the safety, security, and vessel functions are under constant supervision.Features: Monitors and reports switch status Can detect and report problems like opens and shorts in switch circuits Compatible with Maretron Supplied: Heat detectors, Smoke detectors, Carbon monoxide detectors, Bilge water detectors Also compatible with : Magnetic switches, Glass break detectors, Door, hatch, and porthole magnetic switchesSpecifications: Heat Detectors Smoke Detectors Carbon Monoxide Detectors Gas Detectors Bilge Water Detectors Magnetic Switches Glass Break Detectors Clogged Fuel Filter Detection (Excessive vacuum) Door, Hatch, and Porthole Magnetic Switches WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

NMEA2000 Micro Terminator - MaleActisense terminators are exceptionally robust, designed to withstand the harsh conditions of the marine environment, and are easy to install.Each NMEA 2000 installation must have precisely two termination resistors installed, one at each end of the backbone, to ensure proper operation and signal integrity.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledgeTechnical Specifications:Electrical Rated Voltage (power pair) - 60VDC Rated Current - 4A Internal Termination Resistors - 120 Ω ± 1% 500mW Mechanical Male Contact - Brass, gold plated Contact Carrier - PA66 (30% Glass filled), black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, Black Housing - PVC, black Weight - 15g Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -25°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Connection Gender: Male Data Interface: NMEA 2000 NMEA 2000 Connectors: Terminators Box Dimensions: 1"H x 1"W x 2"L WT: 0.1 lbs UPC: 5060998710300 Owner's Manual (pdf)Brochure (pdf)

Read more less

Fuel Flow MonitorPart #: FFM100-01Maretron's FFM100 provides precision fuel flow information to help optimize fuel consumption, which can save thousands of dollars in fuel operating cost. The FFM100 uses state-of-the-art, positive displacement metering technology for unprecedented accuracy. In fact, the accuracy of the FFM100 is nearly that of commercial vessel systems costing tens of thousands of dollars, yet the FFM100 cost less than existing recreational systems found on the market today. Additional benefits of the positive displacement metering technology are the elimination of flow conditioning components such as straighteners and pulsation dampers. Other flow meter technologies require flow conditioning components that increase system and installation cost. The FFM100 also uses true temperature compensation with embedded temperature sensors within the meters. The returning fuel is generally hotter than the supply fuel and if not properly compensated, inaccuracies as much as 5% can occur in computing the engine's fuel consumption. The FFM100 also detects momentary reverse flow in the fuel lines due to fluctuating pressure caused by the injection pump. Less accurate systems count the reverse fuel flow as part of the consumed fuel where the FFM100 properly accounts for momentary reverse flow.Lastly, the FFM100 can be used for fluid types other than fuel (e.g., water, oil, etc.) by ordering the appropriate flow sender.The FPM100 is NMEA 2000® certified so you can view any and all information anywhere on the vessel using a compatible NMEA 2000® display. The FFM100 is a key component of Maretron's N2KView® vessel monitoring and control system. Features: FFM100 converts a variety of flow senders (e.g., fuel, water, etc.) to NMEA 2000® Network Data All flow senders ordered separately depending on application (i.e., single fuel flow sender for gas engine, dual fuel flow senders for diesel engine, water flow sender for sea water, etc.) Fuel flow senders facilitates fuel consumption optimization for reduced fuel operating cost Fuel flow senders use positive displacement metering technology for superior accuracy over other measurement technology such as turbine meters Fuel flow senders do not require costly fuel conditioning components like flow straighteners and pulse dampers Fuel flow senders implement true temperature compensation with precision built-in thermistors for increased accuracy Fuel flow senders automatically detect reverse flow due to fluctuating pressure difference from injection pumps Fuel flow senders pass particle sizes up to 70 micrometers (diesel fuel filters normally filter down to 2 micrometers to prevent clogging injectors) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

NMEA 2000 T-Connector - 6 PortsAs the NMEA 2000 network expands beyond the 3-device limit of Digital Yacht’s NMEA 2000 Starter Kit, users can use this 4-way T-piece to add another four additional devices. With male > female > female connectors, multiple T-pieces can be plugged together or added to the 4-way T-piece included in the starter kit. Also, The 4x lower “drop cable” connector is female so that there are no exposed pins when the drop cable is removed.*Digital Yacht can supply NMEA 2000 cables and connectors to expand the NMEA 2000 to whatever size is needed (up to the maximum 50 NMEA 2000 device limit).Features: NMEA 2000 4 x T-pieces Standard “Micro C” connectors make it very easy for future network expansion Metal connectors improve reliability Waterproof rating of IP68 Quick Guide (pdf)

Read more less

NavLink 2 “NavLink 2 is an easy to fit NMEA 2000 to Wifi server designed to make NMEA 2000 navigation data available for apps on smartphones, tablets, iPads and PCs.” Features:NavLink 2 is an easy to fit NMEA 2000 to Wifi server designed so that NMEA 2000 navigation data can be made available for apps on smartphones, tablets, iPads and PCs. Installation takes seconds as a result of direction connection to the NMEA 2000 back bone and self-powered from the data network.Once installed, it creates a local WiFi network for devices to connect or can be programmed to join an existing wireless network if one is already installed.  This is ideal for devices like the Furuno wireless radar which require operation through their own dedicated network but require NMEA 2000 data integration for charting apps.NavLink 2 now works with the popular Navionics Boating App for Apple iOS and Android. Therefore allowing display of GPS and AIS data on your Navionics charts. Specifications: NMEA 2000 to WiFi server Self powered from NMEA 2000 bus – fits in seconds Supports TCP/IP and UDP connection modes Provides AIS, navigation and instrument data to apps Compatible with all popular apps like iNavX, TimeZero, Weather 4D, Navionics, SailGrib, NavLink, iSailor, SeaPilot, AquaMap etc Up to 7 connected devices Compatible with Windows, Linux, MAC OS, iOS and Android Easy web interface for programming Password protected Can act as dedicated wireless server or rather can connect to an existing wireless network Diagnostic data display mode and LED status lights Internal hi gain WiFi antenna Super-fast 230KBs operation Optional raw data mode for developers and likewise advanced users Supplied with NMEA 2000 cable

Read more less

4-Way Block for NMEA 2000 NetworksNavico's 4-Way Block accessory for NMEA 2000 Networks should be used wheremultiple drop-cables are required in close proximity to make a morecost-effective and streamlined solution compared to installations that usemultiple T-connectors. Specifications: Connection Gender: Female Data Interface: NMEA 2000 NMEA 2000 Connectors: Tee Connectors Box Dimensions: 1"H x 2"W x 6"L WT: 0.15 lbs UPC: 9420024146071

Read more less

NMEA 2000 Cable - 6MFeatures: Length: 6M NMEA 2000 Cable Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 6m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 1"H x 10"W x 10"L WT: 1.6 lbs UPC: 9420024171349

Read more less

N2KEXT-6RD 6' NMEA 2000 Cable 6' NMEA 2000 Cable Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 1.8m NMEA 2000 Connectors: Backbone/Drop Cables Box Dimensions: 3"H x 4"W x 10"L WT: 0.3 lbs UPC: 042194533582

Read more less

Fluid Pressure MonitorMaretron's Fluid Pressure Monitor is used to adapt up to six pressure transducers to the NMEA 2000® network (pressure transducers sold separately). This allows you to observe fluid pressures and tank levels anywhere on the vessel where there are NMEA 2000® compatible displays. With the appropriate transducer, the FPM100 reports either pressure or vacuum for a variety of applications including water pressures, oil pressures, hydraulic pressures, or system vacuum for detecting clogged filters.The FPM100 also has a tank level mode, so that fluid levels in a tank can be monitored via a pressure transducer mounted at the bottom of the tank and transmitted over the NMEA 2000® network. This allows you to monitor the fluid levels in tanks that are extremely deep, have internal structures, or are otherwise not suited for other tank level sensing technologies. In this mode, the FPM100 can be calibrated for irregular tank shapes so that you know the true level of the tanks.The FPM100 is NMEA 2000® certified so you can view any and all information anywhere on the vessel using a compatible NMEA 2000® display. The FPM100 is a key component of Maretron's N2KView® vessel monitoring and control system. Features: Adapts up to six pressure transducers to the NMEA 2000® network Each channel independently programmed to match pressure transducer characteristics Each channel independently programmed in pressure/vacuum mode or tank level mode In Tank Level Mode, measures levels of extremely deep or irregularly shaped tanks Applications Water Pressure Atmospheric Pressure Compressed Air Pressure Hydraulic Pressure Steam Pressure User Defined Pressure Sources Fuel Tank Level/Volume Remaining Fresh Water Tank Level/Volume Remaining Waste Water Tank Level/Volume Remaining WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

RIM100 Run Indicator ModulePart #: RIM100-01Maretron's Run Indicator Module monitors both AC and DC electrical circuits and reports, over an NMEA 2000 network, whether or not the electrical circuit is energized and running. The RIM100 works equally as well for monitoring manually switched loads (running lights, anchor lights, or deck lights) as it does for automatically switched loads. Monitoring automatically switched loads (bilge pumps, engine exhaust/intake fans, and transfer pumps) via the RIM100 is especially useful because you know exactly when equipment is, or isn't running.Features: Monitors and reports the running status of connected devices Works with both AC and DC loads Works with both automatically and manually switched loads Can indicate the status of a wide variety of loads: Bilge bumps, Winches, Running lights, Transfer pumps, Exhaust/intake fans WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

ACM100 Alternating Current MonitorMaretron's ACM100 is a device which monitors AC power sources and outputs information about these sources onto the industry standard NMEA 2000® marine data network. The ACM100 can monitor power busses, generators, or utility power. ACM100 output information is then displayed with networked NMEA 2000® equipment such as the Maretron DSM250 dedicated display or with NMEA 2000® compatible software such as Maretron N2KView. Best of all, the ACM100 is NMEA 2000® certified so you can view any and all AC information anywhere on the vessel using a compatible NMEA 2000® display. The ACM100 is a key component of Maretron's N2KViewr vessel monitoring and control system. Features: Voltage Current Frequency Real Power Reactive Power Apparent Power Power Factor Total Energy Imported Total Energy Exported WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

NAC-FRD2FBLNMEA network adapter cable. Adapts red connector devices to a blue connector network.Works with: NMEA 2000 Compliant Units Specifications: Data Interface: NMEA 2000 Connection Gender: Female-Female Box Dimensions: 2"H x 3"W x 7"L WT: 0.17 lbs UPC: 042194530451

Read more less

NMEA 2000 Blanking Cap - FemaleCovers unused couplers. Protects unused tee connectors from dust and water. Comes in a 2-Pack.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Connection Gender: Female Data Interface: NMEA 2000 Box Dimensions: 2"H x 3"W x 5"L WT: 0.03 lbs UPC: 091887982367

Read more less

NMEA 2000 Drop Cable - 3 MeterThis NMEA 2000 5-pin drop cable is built for seamless integration between your network backbone and connected marine electronics. Designed with durable, waterproof connectors, it ensures a secure and interference-free connection to displays, GPS units, sensors, and more. Built to NMEA 2000 standards, this drop line supports dependable communication across all major marine brands.Whether you’re expanding your system or replacing a worn connection, this marine network cable is an essential component for clean, efficient, and reliable wiring.Made from rugged materials, it resists saltwater corrosion, UV exposure, and mechanical wear, ensuring long-lasting performance in demanding marine environments. Specifications: Connection Gender: Male-Female Data Interface: NMEA 2000 Cable Length (Meters): 3m Box Dimensions: 1"H x 6"W x 11"L WT: 0.5 lbs UPC: 810196330283 Brochure (pdf)

Read more less

The TR3K temperature probe is for use with the Maretron TMP100 Temperature Module (optional extra) or the DCM100 DC Monitor (it is included with the DCM100). This probe ends in a ring terminal and can be used to measure battery temperature or any other under-bolt temperature. The temperature range is -4 deg. F to 176 deg. F (-20 deg C to 80 deg C).WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

J2K100 Adapter Micro Female - Deutsche 4 Pin 2 MeterUse a Maretron J2K100 Adapter Micro Female Deutsche Cordset to attach the J2k100 directly into J1939 networks of compatible engines, transmissions, and gensets. Specifications: Connection Gender: Female Cable Length (Meters): 2m Box Dimensions: 1"H x 6"W x 7"L WT: 0.35 lbs UPC: 873804001449

Read more less

NMEA 2000 Single Tee ConnectorAncor's NMEA 2000 Approved Tee Connectors offer connection between NMEA 2000 drop cables and backbone cables. The yellow couplers connect to the corresponding Ancor tees and backbone cables, creating a simplified, color coded network installation. The connectors are offered in four configurations for maximum installation flexibility. The two way and four way tee connectors allow for multiple drop cables to be connected without additional backbone cable.Features: Color coded for easy installation and component identification NMEA 2000 Approved, 100 percent universal and compatible with other manufacturers' products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Data Interface: NMEA 2000 NMEA 2000 Connectors: Tee Connectors Box Dimensions: 2"H x 3"W x 5"L WT: 0.2 lbs UPC: 091887982268 Brochure (pdf)

Read more less

NMEA 2000 Two Way Tee ConnectorAncor's NMEA 2000 Approved Tee Connectors offer connection between NMEA 2000 drop cables and backbone cables. The yellow couplers connect to the corresponding Ancor tees and backbone cables, creating a simplified, color coded network installation. The connectors are offered in four configurations for maximum installation flexibility. The two way and four way tee connectors allow for multiple drop cables to be connected without additional backbone cable.Features: Color coded for easy installation and component identification NMEA 2000 Approved, 100 percent universal and compatible with other manufacturers' products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Data Interface: NMEA 2000 NMEA 2000 Connectors: Tee Connectors Box Dimensions: 2"H x 3"W x 5"L WT: 0.2 lbs UPC: 091887982282 Brochure (pdf)

Read more less

SPL2000 AIS-VHF Antenna SplitterThe SPL2000 allows the boat's VHF antenna to be used for both an AIS and VHF simultaneously. It uses ZeroLoss technology and is suitable for use with AIS Class B transponder systems as well as AIS receivers. It's also designed as a failsafe device with automatic priority given to the connected VHF. It is supplied with a BNC-BNC patch cable for the AIS and a PL259-PL259 cable for the VHF. It also features a AM/FM wired output for an on board stereo receiver. Identical in size to the AIT2000, it makes the perfect complimentary splitter device for Digital Yacht's range of AIS products.

Read more less

NMEA 0183 Interface CableThe NMEA 0183 interface provides a bi-directional gateway between an NMEA 2000® network and NMEA 0183 devices.Ideal for retrofitting NMEA 2000 devices while retaining existing NMEA0183 components, this interface allows boaters a simple way to upgrade to newer technology, sensors, and devices without replacing a whole system.  For existing NMEA 2000® networks and systems, this also allows a user to add NMEA 0183 devices to your network, allowing you to choose the products best suited to your boat and sailing.Simple mounting, connectivity, and a low-profile design allow for easy installation.Features Easy to install Allows older products to connect to new, more modern products Supports NMEA 0183 Version 4.1 Filter NMEA 0183 rx/tx sentences and configure transmit frequency via Navico® Compatible with Lowrance®, Simrad®, and B & G® MFDs and instrument displays NMEA 2000 Compliant Standard Micro-C connector Specifications: Connection Gender: Male Data Interface: NMEA 0183 Box Dimensions: 3"H x 4"W x 10"L WT: 0.4 lbs UPC: 9420064127658

Read more less

NMEA 2000 Four Way Tee ConnectorAncor's NMEA 2000 Approved Tee Connectors offer connection between NMEA 2000 drop cables and backbone cables. The yellow couplers connect to the corresponding Ancor tees and backbone cables, creating a simplified, color coded network installation. The connectors are offered in four configurations for maximum installation flexibility. The two way and four way tee connectors allow for multiple drop cables to be connected without additional backbone cable.Features: Color coded for easy installation and component identification NMEA 2000 Approved, 100 percent universal and compatible with other manufacturers' products WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Data Interface: NMEA 2000 NMEA 2000 Connectors: Tee Connectors Box Dimensions: 2"H x 4"W x 7"L WT: 0.2 lbs UPC: 091887982299 Brochure (pdf)

Read more less
