| Operating Temperature Range |
"-15°C to +55°C (5° F to 131° F) |
| Storage Temperature Range |
"-20°C to +60°C (4°F to 140°F) |
| SD Card Storage |
1 Micro SD slot, max. 32GB each. >32 GB format to NTFS |
| Ethernet Ports |
1 x 5 pin yellow connector x 1 Mbit. Radar and Sirius (USA only) connectivity only (unless unlocked) |
| NMEA 2000 Connectivity |
1 x NMEA 2000 Micro-C port, 1 LEN |
| Weight |
1.320 kg (2.91lb) |
| Supply Voltage |
10 - 17 V DC |
| Update rate |
10 Hz |
| Power Consumption typical |
12 W |
| Screen Brightness |
1200 nits |
| Dimensions H x W x D |
197 mm x 141 mm x 82.7 mm (7.56" x 5.55" x 3.26") (no bracket) |
| Warranty Period |
2 Years |
| Power Consumption max |
20 W |
| GPS Receiver Channels |
32 Channels |
| Recommended Fuse Rating |
3A |
| Waypoints, Routes, Tracks |
6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points. |
| Viewing Angles |
80° top/bottom, 80° left/right |
| Display Resolution |
800x480 |
| Internal Storage |
90MB |
| Steering Modes |
Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail) |
| Autopilot |
Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail). Requires STBY button or Controller with STBY button to commission |
| Digital Switching |
BEP C-Zone |
| Mounting Type |
Bracket or Panel |
| Approvals Compliance |
CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1 |
| Shock Vibration |
CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1 |
| Time to First Fix |
Cold start less than 90 seconds exposed to open sky, Satellite Reacquisition 5 sec |
| NMEA 0183 Sentences supported |
Exports NMEA0183 over WiFi |
| Radar compatibility |
Halo, Broadband, HD Radars |
| Position Accuracy |
Horizontal Accuracy 3 m (9.8 ft.) |
| Charts supported |
Insight, Navionics (Gold, NAV+ Platinum+) , C-MAP (MAX N, MAX N+) NV Digital (Raster US Charts) |
| Charts Supported |
Insight, Navionics (Gold, NAV+ Platinum+) , C-MAP (MAX N, MAX N+) NV Digital (Raster US Charts) |
| Sonar Compatibility |
Integrated CHIRP / DownScan / ForwardScan. Single 9 Pin Xsonic Connector |
| Item Connectivity WiFi |
Internal |
| Bluetooth |
Internal |
| GPS |
Internal, 10Hz, WASS, MSAS, EGNOS |
| Waterproofrating |
IPX 6 and 7 |
| PC Connectivity |
None |
| Video |
None |
| AIS |
Receive AIS data over NMEA 2000 only |
| Weather |
SiriusXM via WM-3 (USA only), GRIB |
| Catography included |
TBD |
| Interface |
Touch screen, OP40 or OP50 controller via NEA 2000 |
| Manouevres Turn Patterns |
U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking |
| Multimedia |
via SonicHub2, Fusion Link, *Sirius, **JL Audio. *USA only, **AUST. & NZ only) |
| Correction |
WASS, MSAS, EGNOS, GLONASS |
| Backlight Color |
White |
