Autopilot |
Manouevres / Turn Patterns |
U-Turn, C-Turn, Spiral, S-Turn, Square, Zig-zag, Depth |
Steering Modes |
Heading Hold, No Drift, Follow-up, Non-Follow-up, Nav |
Cartography |
Chart Format |
C-MAP Tile (CMT) Discover X, Reveal X C-MAP Tile (CMT) Reveal X |
Charts Supported |
C-MAP Discover™ X, C-MAP Reveal™ X. Third party charts CMOR, StikeLines (check with provider for available content) |
Connectivity |
Bluetooth |
Bluetooth 4.0 with support for Bluetooth Classic (currently not used) |
Ethernet |
1 port (X-Coded M12 GbE) 1 port (yellow, 5-pin) |
NMEA 0183 |
No |
NMEA 2000 |
1 x NMEA 2000 Micro-C port, 1 LEN |
PC Connectivity |
No |
Video |
Video In, IPCAM-1, FLIR 232/300 series. ONVIF IP Camera |
WiFi |
Wi-Fi 5 (IEEE 802.11ax) |
Display |
Backlight Color |
White |
Resolution |
1280 x 800 |
Screen Brightness |
>1200 nits |
Size and Type |
10" SolarMax IPS Touchscreen display for wide viewing angles, extreme clarity and sunlight viewability with polarized sunglasses |
Viewing Angles |
80° top/bottom, 80° left/right |
Electrical |
Power Consumption, max. |
28 W |
Recommended Fuse Rating |
5 A |
Supply Voltage |
12/24 V DC (10 - 31.2 V DC min - max) |
Humidity |
IEC 60945 Damp heat 66°C (150°F) at 95% relative (18 hr) |
Environment |
Operating Temperature Range |
-15°C to 55°C (5°F to 131°F) |
Shock and Vibration |
100,000 cycles of 20 G |
Storage Temperature Range |
-20°C to 60°C (-4°F to 140°F) |
Waterproof rating |
IPX6 and IPX7 |
GPS |
Correction |
10 Hz high speed update (internal) |
GPS Receiver Channels |
32 Channels |
Position Accuracy |
Horizontal Accuracy 3 m (9.8 ft) |
Update rate |
10Hz |
MFD |
AIS |
Receive AIS data over NMEA 2000 |
Autopilot |
NAC-1, NAC-2, NAC3, NAC-D compatible |
Cartography included |
Discover X chart card of North America |
Cartography supported |
C-MAP Discover™ X, C-MAP Reveal™ X. Third party charts CMOR, StikeLines (check with provider for available content) |
Digital Switching |
Czone / DDS |
External Storage |
2x (microSD®, SDHC®) |
GPS |
10 Hz GNSS receiver for GPS and GLONASS, supports combinations with Galileo, Beidou, QZSS. SBAS (WAAS) |
Weather |
Sirius XM via WM4 module (USA only) |
Waypoints, Routes, Tracks |
10,000 waypoints: 75,000 trackpoints: 75 saved tracks: 125 routes. Note: NSS/NSO evo2/3 maximums will apply if on the same network |
Compass Safe Distance - Metric, imperial |
35 cm (1.15 ft) |
Physical |
Dimensions (W x H x D) |
Display only: 287.9 mm x 176.1 mm x 79.6 mm (11.33 in x 6.93 in x 3.13 in) With bracket: 315.8 mm x 196.5 mm x 79.6 mm (12.43 in x 7.73 in x 3.13 in ) |
Mounting Type |
Bracket mount (bracket supplied). Rear mount (brackets supplied) |
Weight |
1.8 kg (3.97 lb) |
