| Frequency Range: Transmit |
156.025?157.425 MHz |
| Frequency Range: Receive |
156.050?163.275 MHz |
| Number Of Channels |
US / INT |
| Oscillate Mode |
PLL |
| Modulation |
FM(16KOG3E) DSC(16K0G2B) |
| Channel Spacing |
25KHz |
| Frequency Stability |
±5 PPM |
| Normal Working Voltage |
+13.6 V DC |
| Minimum operating Voltage |
≥10 V DC |
| Low battery detect Voltage |
10.5 ± 0.5 V DC |
| Digital Selectivity Calling (DSC) |
Class D |
| Intermediate Frequency : 1st |
38.85/21.7 MHz |
| Intermediate Frequency : 2nd |
450 KHz |
| Sensitivity : 12dB SINAD |
≥-6 dBuV(EMF) |
| Squelch Sensitivity: at tight |
≤ 6 dBuV(EMF) |
| Adjacent Channel Selectivity |
≤70 dB |
| Intermodulation Response |
≤68 dB |
| S/N at 3KHz Dev. |
≥40 dB |
| Audio Output Power At THD 10% |
≥2.5 W |
| Audio Distortion |
≤10 % |
| Audio Response |
+1 to -3dB of 6dB/octave from 300hz to 3kHz dB |
| Current Drain : Max Audio Power |
≤1.5 A |
| Current Drain : Stand-By |
≤0.5 A |
| 2ND RX Sensitivity For 12dB SINAD |
≤0 dBuV(EMF) |
| 2ND RX bit error ratio@-107dBm |
≤ 10-2 |
| Frequency error |
≤±1.5KHz |
| RF Power |
Hi23W ± 2W :Lo 0.8W ± 0.2W Hi23W ± 2W :Lo 0.8W ± 0.2W |
| Maximum Deviation Maximum Deviation |
≤± 5 KHz |
| S/N at 3KHz Dev. |
≥40 dB |
| Modulation Distortion ±3KHz |
≤10 % |
| Audio Response at 1KHz Dev. |
+1 to -3dB of 6dB/octave from 300hz to 3KHz |
| Spurious/Harmonic Emissions: Hi/LO |
≤0.25uW |
| Modulation Sensitivity |
≤15 mV |
| Current Drain At 12V DC |
Hi Power ≤6A: Lo Power ≤1.5A |
| DSC TX deviation at 1.3K |
2.6±0.26 KHz |
| DSC TX deviation at 2.1K |
4.2±0.42KHz |
| ATIS TX deviation at 1.3 KHz |
1.3±0.13 KHz |
| ATIS TX deviation at 2.1 KHz |
2.1±0.21 KHz |
