RT Screw Terminal 12 Circuit Dual Lever Bus BarThis Egis bus bar seamlessly integrates with RT fuse blocks, can be used as a standalone ground bus, or can be assembled with an existing RT Series fuse block line. Also, this multi-level low-amp has terminal screws for improved mounting.Applications: The 12-circuit block ensures ground connection reliability with this compact and well-constructed ground bus block. RT series connection compatibility enables a smaller installation footprint and convenient negative terminal access when installed with a fuse block application. Features: Bullet-proof construction - designed with high-temperature materials and stainless steel self-locking hardware, allows mounting anywhere on the vehicle Seamlessly integrates with RT fuse blocks - use as a standalone ground bus or assembled with existing RT series fuse block lines Specifications: Maximum Current (Entire Block) Amps: 100 Maximum Current (Per Circuit) Amps: 30 Max Output Wire Size: #10 AWG Voltage Range VDC: 0-36 Number of Fuse Positions: 12 Output Terminal Connection Ring Terminal Size: M4 / (#8) Focal Features:Robust Materials For Harsh EnvironmentsAll attachment hardware is constructed of stainless steel with self-locking mechanisms for long-lasting installations. A plated copper alloy bus bar conductor withstands corrosion and maximizes conductivity. Engineering-grade composite insulators support high-temperature application exposure, such as in engine compartments.Seamlessly Integrates With RT Fuse BlocksIt can be installed individually on its own or assembled to the end of a 6, 12, or 18-position RT Series fuse block for a more compact overall footprint.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

Terminal Block - 30 Amp - 6 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine-grade materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 65 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Brochure (pdf)

Read more less

MRBF Terminal Fuse - 250 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 250 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 250 Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 1"W x 6"L WT: 0.05 lbs UPC: 850053879661

Read more less

MRBF Terminal Fuse - 200 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 200 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 200a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879654

Read more less

MRBF Terminal Fuse - 150 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 150 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 150a Fuse Type: Terminal Type: Fuses Box Dimensions: 2"H x 2"W x 5"L WT: 0.09 lbs UPC: 850053879630

Read more less

MRBF Terminal Fuse - 50 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 50 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 50a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879562

Read more less

MRBF Terminal Fuse - 60 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 60 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 60a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879579

Read more less

Terminal Block - 30 Amp - 12 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine Grade Materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Specifications: Amperage: 30 Fuse Type: Terminal Box Dimensions: 1"H x 3"W x 10"L WT: 0.3 lbs UPC: 850053879739 Brochure (pdf)

Read more less

XD Relay Cross-Over Bus BarThe XD Relay Cross-Over Bus Bar allows users to link together Egis XD Single, Dual, and Triple XD Relays to each other in multiple configurations and even to the Egis 8700 Mechanical Disconnect.  Linking relays together creates compact installations and allows for robust circuit switching and battery management.Features: Tin-plated copper ensures reliable circuit connectivity and anti-corrosive features keep it last long term. Robust Protective Insulation ensures no accidental contact shorts between XD relays. Specifications: Continuous Current (Amps): 500 Max Voltage (VDC): 72 Material: Tin-plated copper Size (L x W): 90 x 47mm Thickness: 2.8mm (1/8") Terminal Stud Hole Size: 10.5mm (3/8”) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Terminal Block - 30 Amp - 10 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine Grade Materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Specifications: Amperage: 30 Fuse Type: Terminal Box Dimensions: 1"H x 3"W x 10"L WT: 0.25 lbs UPC: 850053879722 Brochure (pdf)

Read more less

Terminal Block - 30 Amp - 8 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine Grade Materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Specifications: Amperage: 30 Fuse Type: Terminal Box Dimensions: 1"H x 3"W x 7"L WT: 0.25 lbs UPC: 850053879715 Brochure (pdf)

Read more less

Terminal Block - 30 Amp - 6 Circuit Marine-grade materials ensure long-lasting reliability in harsh environment applications Screw terminal connection pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair 125 Volt AC or DC rated easily supports 12, 24, 36, & 48 Vdc systems, as well as 120/240 Vac applications Features: Screw Terminal Connection Pairs provide one input and one output screw connected to separate copper alloy bus bars for each matching connecting pair. Terminal blocks are available in 2, 4, 6, 8, 10, or 12 matching connection pairs. Marine-grade materials ensure long-lasting reliability in harsh environment applications. Tin-plated copper alloy conductors, stainless steel hardware, and high-temperature insulation materials deliver a robust solution. 125 Volt AC or DC Rated easily supports 12, 24, 36, and 48 Vdc systems, as well as 120/240 Vac applications (ensure implementation meets applicable accessibility standards as applicable.  Anti-rotation ribs on conductor strips reduce the chance of wire terminal rotation if strain relief distances are long. Protects Ring Terminal Splices from shorting to adjacent circuits or ground with high insulation walls. Bullet-proof Construction: High-temperature insulation material, tin-plated copper alloy conductors, and stainless steel hardware. 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 30 Max Voltage (Vac/Vdc): 250 Dielectric Strength: 2000Vac Hardware Material: Stainless Steel CE Marked: Yes ROHS Compliant: Yes Specifications: Amperage: 30 Fuse Type: Terminal Box Dimensions: 1"H x 2"W x 6"L WT: 0.15 lbs UPC: 850053879708 Brochure (pdf)

Read more less

ATM/MINI 30 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 25 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 20 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 15 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 10 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 7.5 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 5 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.
