2121 Marine Grade Plug & Socket - 12VFor all Scotty High Performance Downriggers, Depthpower Downriggers, and Line Pullers.Features: IP67-rated 12V 30A marine-grade electric plug and socket Comes with flush mount and 90° mounting brackets with a watertight socket cap Rated for use with 10 – 14 gauge wire Recommended use of Premium 10 Gauge 2 Conductor Downrigger Power Wire for wiring your downrigger socket Brochure (pdf)

Read more less

Single XD - NMEA 2000 - Relay with Knobs - 4 Position DTFeatures: Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. 500A continuous / 1600A cranking (per switch) - supports all standard marine electrical systems. Intuitive Manual Control option simplifies operation and awareness of the state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each relay function significant flexibility for OEMs and installers.  90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality Applications: Seamless NMEA 2000 Integration – Control switches, monitor switch status, and battery voltage. Flexible Control Options – Operate via NMEA 2000 or discrete analog inputs for added versatility. 35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Eliminates Dead Start Batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present. Expandable with Link and Cross-Link Busbars to Additional Dual, Triple, or Single XD Relays: Supports 2 or 3 battery systems with standard busbar interconnect accessories. Specifications: Type: Electric Box Dimensions: 3"H x 5"W x 6"L WT: 1.19 lbs UPC: 850067590200

Read more less

XD Series Triple Flex 2 Relay-ACR-Relay with Knobs & 3X DTM ConnectorThe Egis relay replaces three individual high-amp relays with one compact module, reducing space significantly, eliminating the cost of external link cable connections, eliminating the risk of link cable connections vibrating loose, and providing clear, unambiguous awareness of how to operate manual controls and what state the manual controls have forced the relay into.Applications:  Designed to replicate common multi-battery switching and charge management functions - common dual battery load switching via the outer relays and a central automatic charging relay to share charge current are easily implemented Multiple automatic charging relays (ACR) into one device - for 3-4 battery systems that require 2 or 3 ACRs, a single three-relay ACR provides drastic improvements in off-state quiescent current draw, space used, and reduces unnecessary interconnection cables Expandable with link and cross-link busbars to additional dual, triple, or single XD relays - supports 3 or 4 battery systems with standard busbar interconnect accessories Features: Bullet-proof construction - sealed to IP67/IP6K9K, high temperature electronics and materials allow mounting anywhere; stainless steel cable lug studs; large mounting holes accept 1/4-20 / M6 attachment hardware Intuitive manual control option simplifies operation and increases awareness of the state of the manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple programming via dip switches gives each relay function significant flexibility for OEMs and installers. 35-75% reduction in mounting space and product weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts Plug and play compatible with legacy competitor products - single, dual, and triple relay options are available with DTM/ATM connector pins compatible with ML Series bi-stable relays (This relay has 3x DTM connectors) 90-95% less off-state current compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 Cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:Led Status DisplayThe easy-to-see front-facing LED indicator provides visual device status, and the remote LED replicates the local on-device LED. 3-Position Manual overrideForce each relay open or closed, and optionally leave the knob in either position to lock the relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for the included weatherproof label set make circuit and relay identification easy. Blank labels for custom applications. Protective Cover includedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. Stainless Hardware Corrosion is no issue with quality stainless steel studs and self-locking flanged nuts.ProgrammableVia dip switches located under the protective cover. An easy-to-use configuration guide on the reverse makes custom settings a breeze to configure for a wide variety of applications. Smaller FootprintXD relays offer a high amp rating in a smaller package than competitive solutions, reducing installation space requirements to a minimum. Integrated VentHigh-quality Gortex vents regulate internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

NRX Refrigerator AC/DC ConverterDometic™'s AC/DC converter is needed for AC applications.

Read more less

NS-12-20 StartGuardThe abrupt DC system voltage drop that accompanies engine starting can cause micro-processor-driven electronics aboard vehicles or vessels to "dump" programmed memory. StartGuard solves these problems by providing supplemental power to sensitive electronics while the engines are cranking. Newmar's NS-12-20 StartGuard supplies backup power for electronics during engine start. MountingMount the StartGuard in any convenient location, such as under the dash or console, using the four mounting screws provided or #10 bolts.WiringInput from the power source to the electronics must be routed through the StartGuard. Specifications: Input Voltage: 13.8-14.8 VDC nominal, 15.5 VDC Max Relay Activation Input Voltage: 7-15 VDC Output: 20 Amps Max Battery: 12 VDC, 4.0 Amp/Hour, Sealed Rechargeable, 3-5 Year Life (Typical) Backup Capacity (Fully Charged): 20 Amps for one minute/18 Amps for 2 minutes Operating Temperature Range: 0-40 degrees Celsius Winter Storage Temperature Range: -20 degrees to +40 degrees Celsius Dimensions: 8.25" x 4.9" x 3.5" Weight: 5.5 lbs This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

VE. Direct to USB InterfaceThe VE.Direct to USB interface connects products with a VE.Direct connection to devices with a USB port, for example, a computer. With this cable, it is also possible to connect more than two VE.Direct products to a single CCGX. Measures 70.5" in length; 5' 10".WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

CZone Drop Cable - 2MAdapter cable for connecting Mastervolt devices with CZone support to the CZone or NMEA 2000 network. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

USB/USB-C with Deutsch Connector & PlateOffering modern flexibility, this USB/USB-C with Single Plate panel-mount charger provides fast, reliable power for multiple devices in a compact, clean design.Perfect for marine or mobile dashboards, it supports both new and legacy USB-A and USB-C devices, ensuring versatile charging. Built with Deutsch-style connectors for secure, watertight installation, this unit delivers dependable performance in harsh environments while keeping your panel organized and professional-looking.Ideal for upgrading boats, RVs, or off-grid setups, the USB/USB-C with Single Plate charger is a smart solution for efficient multi-device power management.Features: IP66 Protection Mounting Type: Double D Wire Size: 16 AWG  Peak Voltage: 36 V DC 2 Port with Intelligent Device Detection Quick Guide (pdf)Brochure (pdf)

Read more less

VE. Direct - 3M Cable (1 Side Right Angle Connector)Features: Cable Length: 3M 1 Side Right Angle Connector Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

SeaLink® Deluxe 12 Volt Plug Moisture proof sealing ring LED power indicator light Interchangeable 10A fuse Internal strain relief and cord seal Compatible with standard 12V receptacles Max. rating is 10A WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Relay 12V, 75AThis 12V, 75-amp relay is great for automotive applications. Bi-furcated contacts ensure long-term reliability and increased operating efficiency.Applications: Bi-furcated contact reduces contact bounce and increases long-term reliability. This enables the relay to conduct electrical switching more efficiently, reducing unnecessary heat buildup and contact wear. The high intermittent amperage rating of 150 amps for up to 3 seconds, makes this relay great for temporary high-equipment start-up amp draw applications. Offset input/output terminals and an integrated divider design help prevent accidental contact shorts A high-temperature rating of 125 degrees C/257 degrees F makes this a great relay for high-temperature installation environments like engine bays and other low-ventilation spaces. Features: Bullet-proof construction - Robust automotive grade relay with IP54 ingress protection and reinforced mounting tabs ensure secure mounting Dual mounting holes on either side for easy mounting with ¼-20”/M6 1.25 bolts or screws up to #14 screw Incorporate the highest quality materials for superior performance and have a high 100,000 electrical switching cycle capacity Enhanced vibration and shock protection ensures enhanced reliability, a long service life, and the operational readiness of the electrical system Specifications: Intermittent Current @ 3 SEC (Amps): 150 Ambient Temp. Rating (Low/High) (Celsius): -50/125 C Max Continuous Current (Amps): 75 @23 degrees C Electrical Endurance Rating (Cycles): 100,000 Initial Contact Resistance (6VDC) 50 mOhm Operating Voltage Range: 8.8-16VDC Focal Features:Long-Term ReliabilityBuilt from high-quality materials, this relay offers superior electrical switching performance for long-term use in applications.Locking HardwareZinc-plated M5-size input/output terminal screws with held-in-place nuts keep connections secure and allow easy tightening of wire terminations.Automotive GradeWide operational temperature ratings and shock/vibration resistance make this a great relay for an automotive electrical system. Meets or exceeds IEC 60068-2-27 and IEC 60068-2-6, IP54, and IEC 60068-2-2 ratings.Varied Fastener Sizes6mm x 8.7mm elongated holes accommodate up to 1/4-20" or M6x1.25 bolts or up to #14/1/4" sized screws and allow for centering adjustment when installing relays.Reinforced MountingRobust mounting tabs with strengthening gussets ensure the relay stays mounted securely, even through vibration, heat, and wire tension.Compact SizeA small mounting footprint is great for confined installation spaces where space is at a premium.Flat Blade ConnectorsShielded dual 6.3 x.03 mm flat male terminal connectors allow for quick, secure, and easy control wire connections.Offset TerminalsIntegrated divider tab design and varied mounting height input/output pads protect accidental contact shorts.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

1810Features: Accurate - used with the Vessel Systems Monitor VSM 422 PN 1800 - can be precisely calibrated for each tank* Reliable - SSI Technologies, Inc. Fluid-Trac® is non-contacting eliminating any mechanical moving parts that can wear and cause intermittent or complete signal loss Digital filtering - Eliminates errors due to liquids sloshing in mobile tanks * Calibrated for use with Blue Sea Systems Vessel Systems Monitor VSM 422 only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Current Model Outboard Solenoid with Flat Isolated BaseThe outboard solenoid will fit the current model Mercruiser and Mercury. Isolated base, 12 Volt.Replaces:MERCURY 89-850189MERCURY 89-850189TMERCURY 89-91975MERCURY 89-96054MERCURY 89-96054T*ARCO Assurance 12-month part and labor warranty protectionThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Type: Parts Box Dimensions: 2"H x 4"W x 4"L WT: 0.37 lbs UPC: 693006001616

Read more less

Motor Reversing ModuleThe forward and reverse module automatically reverses the direction of the motor when the appropriate control circuit is energized with a pulse from a control switch. Dynamic breaking stops the motor when the switch returns to Off. Ideal for tarp or lift applications as well as for use on hoists, hatches, winches, snowplows, intake/exhaust fans, vehicle outriggers, and other reversing applications. Low-profile module saves space. Studs are securely anchored in epoxy. Tin-plated brass studs and hardware for corrosion resistance. Quick Guide (pdf)

Read more less

AC Power Supply 20/25A, 12V Out, 85-265V InThe PWI320 Intelligent Power Supply delivers a full 300 watts of output power for communications, control or a wide variety of other devices. It is fully Digital Signal Processor controlled and feature Universal Input Voltage from 85 to 265 VAC at 50 or 60 Hz with Active Power Factor Correction for the most efficient use of AC power.The Power Supply is preset to the same voltage as a fully charged battery of the nominal output voltage (ie. 13.6V for a 12V model, etc.). The voltage can be adjusted over a reasonable range using the front panel controls, or the PowerWizard software that is free to download from www.analyticsystems.com.Seven dual color LEDs clearly indicate output current levels as well as indicating faults with the Power Supply. Safety features include Power Supply over temperature shutdown, current limiting, short circuit protection, input under voltage shutdown and output overvoltage protection all with automatic recovery.  PWI320MW model available with MIL connectors, extra input and output filtering and sealed to IP66Features: Digital Signal Processor controlled Universal worldwide AC input Computer programmable Simple front panel controls Easy connection to loads High Vibration Rugged Duty Dry Contact Output Fail Relay Carrying Handle Canbus / RS232 / Remote Control port Five year parts and labour warranty Specifications: Charger Input - Voltage: 85-265v Charger Output - Amps: 20-25a Charger Output Voltage: 12v Box Dimensions: 7"H x 11"W x 12"L WT: 8.3 lbs

Read more less

Marine 12-Volt Power Outlet Marine quality 12-volt outlet Designed to for replacing or adding outlets in your boat RV or camper Surface mount WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

DT Deutsch Socket for 14-18 AWG Plug - Size 16 Contact (25 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability, which are just a few of the reasons that professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is that they are simple to use and require little time for installation.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Compliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Characteristics:Hand-insertable contactsSpecifications: Package Size: 25 sockets Contact Size: 16 Wire Size: 14 Operating Temperature: -55°C to 125°C Current Rating: 7.5-25

Read more less

Ultra Magnetic Waterproof Wireless Charger - 15W - 12/24VMag. Charge. Connect.Experience the power of the Ultra, the first Qi2-certified, mag-compatible marine-grade phone charger. Built for durability and performance, it features an IPX6 waterproof rating (front and back) and toughened glass.Ultra is fast - our smallest and fastest waterproof wireless charger yet!With our Mag technology, your Apple iPhone magnetically locks into the optimal charging position, delivering a secure and reliable connection every time.This waterproof 12/24V wireless charging system, engineered specifically for the marine environment, eliminates cable clutter while keeping your phone charged and accessible, even in the harshest conditions. Its strong magnetic grip ensures your phone stays securely in place during rough rides, making it the ultimate onboard charging solution.TestingSubjected to our harshest environmental, vibration, impact, and on-water testing programs. This is combined with our world-renowned expertise in waterproofing technologies, UV stabilisation techniques, and premium-grade materials to ensure Ultra is the best choice for mounting and wirelessly charging your phone outdoors.What is Qi2?Qi2 is the latest evolution in wireless charging, developed by the Wireless Power Consortium (WPC). Designed for faster, more efficient power delivery, Qi2 offers up to 15W of charging and features magnetic alignment for a seamless, optimized charging experience. As a leader in marine technology, Scanstrut is bringing this next-generation standard to the water, ensuring reliable, high-performance charging wherever your adventures take you.Features: 15W fast charging Magnetically holds the phone IPX6 waterproof rated: Front & back Toughened glass Qi2-certified Specifications: Input Voltage Range: 10-30V DC (12/24V system) Input current max: 2A Output Power: 15W Standby Power Draw: <0.5W Certification: Qi2, CE, ROHS, FCC, C-Tick, WEEE, UN ECE R10, PSE Certified Specifications: Type: Chargers Box Dimensions: 3"H x 3"W x 5"L WT: 0.6 lbs UPC: 5060114799448 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

PowerGuard PRO Battery BoxExperience the difference between PowerGuard PRO Series Battery Protection Upward-facing vents let gases out while reducing water in-take by 94% - vs. PowerGuard 27 Series Polypropylene composite material is impervious to acid leaks and other external factors Engineered spill channels direct water away from the battery With PowerGuard PRO, the battery is always within reach Folding entry panels provide easy access to the battery terminals without the need to remove the mounting strap A versatile bidirectional design allows contact from any angle Ergonomic handles provide more comfort when transporting the battery PowerGuard PRO takes security seriously Reinforced mounting hardware ensures the battery and box stay anchored Spacer blocks are removable to fit Group 24, 27, and 31 batteries The snap-locking lid gives confidence that the battery will remain secure Specifications: Dimensions with Lid Installed - Internal Dimensions (L x W x H): 13-1/8" x 7" x 11" Outside Dimensions (L x W x H): 21" x 11-1/4" x 11-1/2" Color/Style: Black/Vented Quick Guide (pdf)

Read more less

Round USB & USB-C Power Plug with VoltmeterUSB 3.0 & USB-C Power Plug with Volt Meter charges two devices simultaneously while the LED screen displays voltage status. Can be used on a boat, car, or RV. The total output 6A load is split 3A per side as needed. USB 3.0 features Quick Charging (QC) for supported devices, giving enough power to charge phones, pads, and tablets quickly and efficiently. USB-C features Power Delivery (PD) for faster and more flexible charging. Features:  This portable version fits all Sea-Dog® Power Sockets and any standard 12V receptacle Constructed of aluminum and injection molded nylon Blue LED display FCC, CE, RoHS compliant Specifications: Output DC: 5V/6A  Input: 8-32VDC  USB-C Watts: 60W@24V  USB 3.0 Watts: 36W@12V Plug-In Side Diameter: (inch) 1-1/4" Length: (inch) 2-1/2" *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 15AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 15a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.15 lbs UPC: 850074331025 Brochure (pdf)

Read more less

TDR Series Dual Output Time Delay Relay 12V (2 x 80A)This 12V dual-time relay can prevent dead batteries due to added equipment loads on after-engine stops or from multiple systems connected to a battery with an independent keep-alive power draw, maximizing operational readiness.Applications: Supports on-board video systems when vehicles are not in use, allowing lengthy downloading while shutting down less time-sensitive equipment. sooner. Protects sensitive onboard electronics via optional under/over voltage shutdown and start event isolation. Features: Eliminates vehicle downtime due to dead batteries; the lowest off-state current draw (1.3 mA) is available Simple and robust Installation - Sealed plug with optional long wire leads; Single device replaces multiple control units and high-amp replays reduce installation time, costs, and points of potential failure Additional low-amp output can be used to maintain 24-hour memory circuits or to direct other equipment to shut down Bullet-proof construction - Sealed unit and high-temperature materials allow mounting anywhere on the vehicle; Integrated thermal overload protection as well Meets stringent OEM standards for electrical transient self-protection Adjustable OFF Time Delay - 0 seconds to 4 hours Kill Switch control input option for ensuring loads are not inadvertently on, maintenance/servicing of vehicles, and emergency OFF Flexible control options via ignition key, alternator voltage sense, or both 4 Year Industry Leading Warranty Specifications: Maximum Current: Continuous: 80 Amps DC per Output (160 A Total); Intermittent: 120 Amps DC (5 Minutes) per Output Off-State Current Draw: 1.5 mA (less than 1 Amp-hr battery dissipation per month of stand-by) Operating Specifications: Voltage: 12 Vdc Nominal (8 - 18 Vdc); Temperature: -40 to 85 degrees C Time Delay Options: 5 Sec through 4 hours via Dip Switches Environment Protection Standards: Waterproof to IP66. IP6K9K; Ignition Protected to ISO 8846 Optional Features: Input stud voltage sense trigger for relay OFF; Under-voltage and over-voltage load protection Focal Features:Top Side Dip SwitchesAccessible after installation, for programming time delay and determining active features. Protected by self-retained cover.Stainless Steel Self-Locking Hardware 100% Non-ferrous corrosion-resistant materials. All attachment screws and nuts are self-locking.Integral I/O Connector Rapid and 100% correct assembly via Molex MX-150 connector eliminates poor field connections.Standard and Optional Harnesses The mating plugs with 2 feet of the ground and ignition wire included. Optional harnesses with additional outputs and alternate wire lengths are availableEasy Integration with CT Fuse Blocks Optional EasyLink bus bars reduce the space and cost of connecting TDRs with CT series Fuse Blocks.Easy Integration with RT Fuse Blocks Optional EasyLink bus bars reduce the space and cost of connecting TDRs with RT series Fuse Blocks.LED DiagnosticsIndicates a pending relay OFF event due to under/over voltage or external off trigger. Output on/off status is also provided.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 5AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 5a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.2 lbs UPC: 850074331087 Brochure (pdf)

Read more less

A Series Black Toggle Panel Mount Circuit Breaker - Single Pole 5AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 5a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.1 lbs UPC: 850067590996 Brochure (pdf)

Read more less

Terminal Block 20A - 4 CircuitFeatures: Marine Grade Materials Ensure Long Lasting Reliability In Harsh Environment Applications. Screw Terminal Connection Pairs Provide One Input And One Output. Screw Connected To Separate Copper Alloy Bus Bars For Each Matching Connecting Pair. 125V AC or DC Rated Easily Supports 12, 24, 36, 48 Vdc Systems, As Well As 120/240 VAC Applications. Specifications: Type: Electric Box Dimensions: 2"H x 3"W x 10"L WT: 0.15 lbs UPC: 850074331360

Read more less

MT Series 9+3 Sealed Fuse Block with Ground BusbarFeatures: Integrated Deutsch/Amphenol Output Connectors Protects add-On Circuits From Accidental Shorts To Frame Ground Or Battery Negative, Or From Overload Events Expandable with Flex System Compatible Interconnect Busbars For Plug-and-Play Install Split Input 9+3 Circuits *Fuses and Circuit Breakers Sold Separately Brochure (pdf)

Read more less

MT Series 6+6 Sealed Fuse Block with Ground BusbarFeatures: Integrated Deutsch/Amphenol Output Connectors Protects add-On Circuits From Accidental Shorts To Frame Ground Or Battery Negative, Or From Overload Events Expandable with Flex System Compatible Interconnect Busbars For Plug-and-Play Install Split Input 6+6 Circuits *Fuses and Circuit Breakers Sold Separately Brochure (pdf)

Read more less

XD Single Low Voltage Disconnect without Knob - Tinned WiresFeatures: Up to 500 Amp Continuous Capability Per Relay / Extremely Compact Footprint Available With or Without Intuitive Front-Facing Manual Override Knobs with the ability to Lock Relay ON or OFF for Servicing Flexible Functionality via Dip Switches: Low Voltage OFF Set-Point, Delay Off Time, and Voltage Differential for Warning Signal Remote ON/OFF/Auto Inputs Allow Forced Close or Open or Allow Automatic Operation Based on Voltage Sensing LED Indicator Provides Helpful Diagnostics Remote External Warning Alarm Control Signal Provides Warning of Impending Voltage-Based Shutdown Specifications: Type: Electric Box Dimensions: 3"H x 5"W x 6"L WT: 1.09 lbs UPC: 850067590149

Read more less

XD Single Low Voltage Disconnect with Knob - Tinned WiresFeatures: Up to 500 Amp Continuous Capability Per Relay / Extremely Compact Footprint Available With or Without Intuitive Front-Facing Manual Override Knobs with the ability to Lock Relay On or OFF for Servicing Flexible Functionality via Dip Switches: Low Voltage OFF Set-Point, Delay Off Time, and Voltage Differential for Warning Signal Remote ON/OFF/Auto Inputs Allow Forced Close or Open or Allow Automatic Operation Based on Voltage Sensing LED Indicator Provides Helpful Diagnostics Remote External Warning Alarm Control Signal Provides Warning of Impending Voltage-Based Shutdown Specifications: Type: Electric Box Dimensions: 3"H x 5"W x 6"L WT: 1.1 lbs UPC: 850067590132

Read more less

MT Series 3+9 Sealed Fuse Block with Ground BusbarFeatures: Integrated Deutsch/Amphenol Output Connectors Protects add-On Circuits From Accidental Shorts To Frame Ground Or Battery Negative, Or From Overload Events Expandable with Flex System Compatible Interconnect Busbars For Plug-and-Play Install Split Input 3+9 Circuits *Fuses and Circuit Breakers Sold Separately Brochure (pdf)

Read more less

Rainbow Display Digital Voltmeter - Injection Molded Nylon - 5V-15VDCThe Rainbow Display Digital Voltmeter gives the user quick, visual, color-coded voltage information. Red/orange means the voltage is too low. Green means the voltage is normal. The same compact round size as a standard 12VDC receptacle, this voltmeter supports many installation options. Constructed of injection-molded nylon. Rainbow LED display. For use with 12VDC systems. IP65 rating.Specifications:Volts: 5-15

Read more less

36" SAE Power Cable Polarized Electrical ConnectorThis SAE-type polarized electrical connector is a two-prong plug and socket connector set. Features:14-gauge duplex wireSpecifications: Length: 36 in. Volts: 12-24 Max Amps: 20A @ 12V Wire Gauge: 14 AWM Weight: 0.17 lb. Specifications: Type: Cables Box Dimensions: 1"H x 5"W x 9"L WT: 0.15 lbs UPC: 035514432757 Brochure (pdf)

Read more less

USB A / USB C Square Surface Mount Power SocketThis square surface-mount USB 3.0 & USB-C power socket charges two devices simultaneously. When split, the total 6A output is 3A per side. Features: USB 3.0 features Quick Charging (QC) for supported devices gives enough power to charge phones, pads, and tablets quickly and efficiently USB-C features Power Delivery (PD) for faster and more flexible charging A protective dust cap covers ports when not in use Constructed of injection-molded nylon Easy installation requires drilling a 3/16-in. hole for the wire connection, securing it to the surface with two #6 screws (not included), and snapping the concealed fastener cover in place Blue LED illumination IP65 rating CE & RoHS compliant Specifications: Output DC: 5V/6A Input: 8-32VDC USB-C Watts: 60W@24V USB 3.0 Watts: 36W@12V Dimensions (inch): 1-15/16” – 1-15/16” Depth: 3/4 in. Volts: 8-32 Weight: 0.07 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Lanocote Rust & Corrosion Solution - 16 oz. LanoCote works on these five basic principles: displaces water, absorbs corrosion, forms moisture barrier, penetrates and high lubricity. LanoCote is extremely effective in preventing and stopping corrosion on all types of metals under all environmental conditions. Formulated to withstand salt water marine conditions, LanoCote is particularly useful in preventing thread seizure due to all types of corrosion on boats and machinery.Applied during assembly, LanoCote will greatly assist in easy dismantling years later. An example would be anchor shackles which are regularly immersed in salt water. LanoCote also combats galvanization where dissimilar metals are fastened together, such as stainless steel fittings on alloy masts etc. Features: Prevents Thread Freeze-up Combats Galvanic Reaction of Dissimilar Metals Seals Porous Surfaces Neutralizes Acids, Alkalies, & Salts Prevents Corrosion on Electronic Contacts Specifications: Type: Corrosion Protection Box Dimensions: 4"H x 4"W x 4"L WT: 0.95 lbs UPC: 028026136268

Read more less

Yellow 18 AWG Wire Ferrule - 6mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features: Prevent strand separation while minimizing strand breakage Insulated ferrules provide additional electrical insulation Increase connection reliability when terminating stranded wire in terminal blocks Specifications: Package Size: 25 Wire Size (AWG): 18 Insulation Color: Yellow Ferrule Length: 6mm (0.24 in.) Stripping Length: 8mm (0.31 in.) Quick Guide (pdf)

Read more less

XD Flex 2 Dual VSR/Mech with Knob - 6-Pin DTM ConnectorHighly compact, 500 AMP dual relay and Automatic Charging Relay (ACR). It is designed to save space by consolidating multiple heavy-duty relays and charge management systems into a single sealed, programmable module. Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 6"L WT: 1.75 lbs UPC: 850053879517

Read more less

XD Dual Flex 2 Relay/Relay with Knobs - Tinned WiresFeatures: Compact 35-75% smaller installation footprint than competitive solutions Flexible functionality via dip switches: utilize each as a relay/battery disconnect or automatic charging relay. Supports single/multiple engine installations with dual start/enging isolation inputs. Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 7"L WT: 1.9 lbs UPC: 850074331902 Brochure (pdf)

Read more less

XD Flex L Triple (Relay/ACR/Relay) with Knobs - DTMDesigned for Lithium-ion, Lithium Polymer, and Lithium Iron Phosphate Battery Systems Where Required Charge / Discharge Voltage Settings Require Higher Available Settings500 Amp Continuous Capability Per Relay / Extremely Compact FootprintAvailable with or without Intuitive Front-Facing Manual Override Knobs with the ability to Lock Relays ON or OFF for ServicingFlexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Voltage Sensing Relay, or Low Voltage DisconnectRemote ON/OFF/Auto Inputs to Force Each Relay Closed, Open, or to Allow Automatic Operation Based on Voltage SensingLocal and Remote LED Indicators Per RelayMechanical-Only Battery Switch Option for One or Multiple Relay PositionsFeatures: Ultra-Low Power Draw: Lowest off-state current draw in the industry (1.3mA) combined. Simple & Robust Installation: Sealed Deutsch/Amphenol DTM/ATM or DT/AT connectors available. Flying wire harnesses also available. Flexible Application Options: Install as a Remote Battery Disconnect Switch, Voltage Sensing Relay, or Low Voltage Disconnect. On/Off trigger via external signal and/or alternator voltage sense. Diagnostic Feedback:  Via optional external LEDs control lines and on-board LEDs for each relay Bulletproof Construction: Sealed unit, high-temperature materials allow mounting anywhere on the vehicle. Integrated thermal overload protection. Optional Manual Override provides power loss backup operation and the ability to lock OFF switched loads in order to service downstream circuits. Meets Stringent OEM Standards for electrical transient self-protection 4 Year Industry-Leading Warranty Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 8"L WT: 2.71 lbs UPC: 850074331698 Brochure (pdf)

Read more less

XD Dual Flex L VSR/Relay with Knob - 6-Pin DT ConnectorDesigned for Lithium-ion, Lithium Polymer, and Lithium Iron Phosphate Battery Systems Where Required Charge / Discharge Voltage Settings Require Higher Available Settings500 Amp Continuous Capability Per Relay / Extremely Compact FootprintAvailable With or Without Intuitive Front Facing Manual Override Knobs with the ability to Lock Relays ON or OFF for ServicingFlexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Voltage Sensing Relay, or Low Voltage DisconnectRemote ON/OFF/Auto Inputs to Force Each Relay Closed, Open, or to Allow Automatic Operation Based on Voltage SensingLocal and Remote LED Indicators Per RelayMechanical-Only Battery Switch Option for One or Multiple Relay PositionsFeatures: Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. Intuitive Manual Control option simplifies operation and awareness of the state of manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers.  35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Plug & Play Compatible with Legacy Competitor Products:   Single, dual, and triple relay options are available with DTM/ATM connectors, pin-for-pin compatible with ML Series Bi-stable Relays. 90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality 4 Year Industry-Leading Warranty Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 7"L WT: 1.89 lbs UPC: 850067590163 Brochure (pdf)

Read more less

A Series Black Toggle Panel Mount Circuit Breaker - Single Pole 8AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 8a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.21 lbs UPC: 850074331001 Brochure (pdf)

Read more less

A Series Black Toggle Panel Mount Circuit Breaker - Single Pole 25AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 25a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.21 lbs UPC: 850067590965 Brochure (pdf)

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 30AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 30a Box Dimensions: 2"H x 4"W x 4"L WT: 0.21 lbs UPC: 850074331056 Brochure (pdf)

Read more less

XD Flex 1 Triple Relay/VSR/LVD with Knob - 6-Pin DTM ConnectorFeatures: 500 Amp Continuous Capability Per Relay / Extremely Compact Footprint Available With or Without Intuitive Front Facing Manual Override Knob with the ability to Lock Relays ON or OFF for Servicing Flexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Automatic Charging Relay, or Low Voltage Disconnect Supports Single/Multiple Engine Installations with Dual Start/Engine Isolation Inputs Remote ON/OFF/Auto Inputs allow forced close or open, or allow automatic operation based on Voltage Sensing Local and Remote LED Indicators for Each Relay Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 8"L WT: 2.66 lbs UPC: 850035199862

Read more less

TH3 Dual Relay 2 x 80A - 12VFeatures: Replaces Manual Battery Switches: Reduces battery cable run lengths and resulting voltage drop Connect to the Ignition Signal for simple battery charge management between two batteries or for simple auxiliary load disconnection. Connect to TH Series Automatic Charging Relays or Time Delay Relays to provide an additional isolated/switched output or to extend current-carrying capability Simple & Robust Installation: Sealed MX-150 plug/harness with 2ft control wires included. Reduces install time/costs. The optional output bus bar provides a simple, compact connection to the RT or CT fuse block product families. Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere on the vehicle. Stainless steel self-locking hardware Single or Dual Split Output Options provide flexibility for different electrical system requirements Integral Diode Suppression reduces voltage spikes on control lines during switching Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 7"L WT: 0.82 lbs UPC: 850035199909 Brochure (pdf)

Read more less

XD Single - Flex Relay/ACR No Knobs - Tinned WiresFeatures: 500 Amp Continuous Capability / Extremely Compact Footprint Available with or without Intuitive Front Facing Manual Override Knob, with the ability to lock the device on or OFF for Servicing Flexible Functionality via Dip Switches, utilize as a Relay/Battery Disconnect, Automatic Charging Relay, or Low Voltage Disconnect Supports Single/Multiple Engine Installations with Dual Start/Engine Isolation Inputs Remote ON/OFF/Auto Input Allows Forced Close or open, or allows automatic operation based on Voltage Local and Remote LED Indicators Specifications: Type: Electric Box Dimensions: 3"H x 5"W x 6"L WT: 1.1 lbs UPC: 850035199244

Read more less

XD Triple Flex L (Relay) - (ACR) - (Relay) with Knobs - Tinned WiresDesigned for Lithium-ion, Lithium Polymer, and Lithium Iron Phosphate Battery Systems, Where Required Charge / Discharge Voltage Settings Require Higher Available Settings500 Amp Continuous Capability Per Relay / Extremely Compact FootprintAvailable with or without Intuitive Front Facing Manual Override Knobs with the ability to Lock Relays ON or OFF for ServicingFlexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Voltage Sensing Relay, or Low Voltage DisconnectRemote ON/OFF/Auto Inputs to Force Each Relay Closed, Open, or Allow Automatic Operation Based on Voltage SensingLocal and Remote LED Indicators Per RelayMechanical-Only Battery Switch Option for One or Multiple Relay PositionsFeatures: Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. Intuitive Manual Control option simplifies operation and awareness of the state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers.  35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Plug & Play Compatible with Legacy Competitor Products:   Single, dual, and triple relay options available with DTM/ATM connectors, pin for pin compatible with ML Series Bi-stable Relays. 90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality 4 Year Industry-Leading Warranty Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 8"L WT: 2.67 lbs UPC: 850053879432 Brochure (pdf)

Read more less

XD Dual Flex L (ACR) - (Relay) with Knobs - Tinned WiresDesigned for Lithium-ion, Lithium Polymer, and Lithium Iron Phosphate Battery Systems Where Required Charge / Discharge Voltage Settings Require Higher Available Settings500 Amp Continuous Capability Per Relay / Extremely Compact FootprintAvailable With or Without Intuitive Front Facing Manual Override Knobs with Ability to Lock Relays ON or OFF for ServicingFlexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Voltage Sensing Relay, or Low Voltage DisconnectRemote ON/OFF/Auto Inputs to Force Each Relay Closed, Open, or to Allow Automatic Operation Based on Voltage SensingLocal and Remote LED Indicators Per RelayMechanical-Only Battery Switch Option for One or Multiple Relay PositionsFeatures: Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. Intuitive Manual Control option simplifies operation and awareness of state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers.  35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Plug & Play Compatible with Legacy Competitor Products:   Single, dual and triple relays options available with DTM/ATM connectors pin for pin compatible with ML Series Bi-stable Relays. 90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality 4 Year Industry-Leading Warranty Specifications: Type: Electric Box Dimensions: 3"H x 6"W x 6"L WT: 1.9 lbs UPC: 850053879425 Brochure (pdf)

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 50AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 50a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.22 lbs UPC: 850074331070 Brochure (pdf)

Read more less
